Leutert 50 - The Drum, Complete

10 Friedrich Leutert GmbH & Co. KG
Engine Indicators Type 50 and Type 30 - Operating Instructions
2.1.4 The Drum, complete
Item Description
Part-No.
Type 50 Piston 1/10 Type 50 Piston 1/5 Type 30
*)
Piston 1/5
38 Drum, complete 4661.11.01000 4661.11.01000 4611.11.010 0 0
39 Drum knob 4651.11.01001 4651.11.01001 4651.11.01001
40 Drum axle 4651.11.01002 4651.11.01002 4611.11.010 01
41 Drum spring 4651.11.01003 4651.11.01003 4611.11.010 02
42 Drum cylinder 46 61.11.01101 4 661.11.01101 4 611.11.01101
43 Paperclamp, long 4 651.11.01102 4651.11.01102 4611.11.01102
44 Paperclamp, short 4 651.11.01103 4651.11.01103 4611.11.01103
45 Drum cover 4661.11.01201 4661.11.01201 4 611.11.01201
46 Cylindrical pin KBSTIFD03.03300 KBSTIFD03.03300 KBSTIFD03.03300
39
45
44
41 (hidden)
42
40
43
46 (hidden)
46 (hidden)
*)
Discontinued product. No availability of spare parts. Availability of complete units while stock last.
