12 Friedrich Leutert GmbH & Co. KG
Engine Indicators Type 50 and Type 30 - Operating Instructions
3 The Indicator Spring
3.1 Indicator Type 50
3.2 Indicator Type 30
Piston Piston Ø Scale Max. Pressure Spring-No. Part-No.
1/10 6.41 mm 0.35 mm/bar 140 bar 50 / 14 bar 4651.71.14000
1/10 6.41 mm 0.30 mm/bar 160 bar 50 / 16 bar 4651.71.15000
1/10 6.41 mm 0.25 mm/bar 200 bar 50 / 20 bar 4651.71.16000
1/10 6.41 mm 0.20 mm/bar 250 bar 50 / 25 bar 4651.71.17000
1/10 6.41 mm 0.15 mm /bar 300 bar 50 / 30 bar 4651.71.18000
Piston Piston Ø Scale Max. Pressure Spring-No. Part-No.
1/5 9.06 mm 0.20 mm/bar 150 bar 30 / 30 bar 4611.71.14000
1/5 9.06 mm 0.16 mm/ bar 200 bar 30 / 40 bar 4611.71.16000
1/5 9.06 mm 0.12 mm/bar 250 bar 30 / 50 bar 4611.71.17000
