Leutert 50 - The Bottom Part, Complete; The Upper Part, Complete

8 Friedrich Leutert GmbH & Co. KG
Engine Indicators Type 50 and Type 30 - Operating Instructions
2.1.1 The Bottom Part, complete
2.1.2 The Upper Part, complete
Item Description
Part-No.
Type 50 Piston 1/10 Type 50 Piston 1/5 Type 30
*)
Piston 1/5
14 Upper part, complete 4656.11.10000 4651.11.10000 4611.11.10000
15 Turning ring lock screw 4651.11.100 01 4651.11.10 001 4 611.11.10 0 01
16 Elastic washer 4651.11.10 002 4651.11.100 02 N.A.
17 Spring support 4651.11.10 006 4651.11.10 006 4 611.11.104 01
18 Headless stud 4651.11.100 09 4651.11.100 09 4611.11.10 4 03
19 Ring nut 4651.11.1010 0 4651.11.1010 0 4 611.11.1010 0
20 Spring cap 4651.11.10300 4 651.11.1030 0 4 611.11.103 00
21 Piston rod c/w piston 4656.11.10100 4651.11.10200 4611.11.1020 0
22 Recording mechanism 4651.11.110 0 0 4 651.11.110 0 0 4 611.11.1200 0
Item Description
Part-No.
Type 50 Piston 1/10 Type 50 Piston 1/5 Type 30
*)
Piston 1/5
10 Bottom part, complete 4651.11.03100 4651.11.03200 4 611.11.0310 0
11 Straight pin ZSTIFTD02.25600 ZSTIFTD02.25600 ZSTIFTD02.25600
12 Wedge 4651.11.03102 4651.11.03102 4651.11.03102
13 Coupling nut 4651.11.03103 4651.11.03103 4651.11.03103
11
13
12 (hidden)
20
17
15
22
21
19
18 (hidden)
16 (hidden)
*)
Discontinued product. No availability of spare parts. Availability of complete units while stock last.
