INTRODUCTION

Levelpro Submersible Level Transmitters are manufactured for years of trouble free service in tough industrial applications. The 100

Series Levelpro Submersible Level Transmitter measures the height of liquid above the position of the sensing diaphragm of the

transmitter located inside the tank referenced to atmospheric pressure. The transmitter consists of a ceramic piezo-resistive sensing

element, encased in PVC, PVDF, PP, or 316 SS housing.

The Large Diameter flush diaphragm is non-clogging and damage resistant to floating solids.

The 100 Series transmitter is equipped with a high tensile strength FEP (Teflon) shielded and vented cable. and contains an internal

non-wetted weight and utilizes Kalrez O-ring seals The Ventilation tube in the cable automatically compensates for changes in

atmospheric pressure above the tank.

Excellent Chemical Compatibility PVC | PVDF | PP | 316SS

Slim Design for Tight Applications

Large Diameter, Non-Clogging, Damage Resistant, Ceramic Diaphragm

This operating manual contains important information on proper usage of the device. Read this operating manual carefully before

installing and starting up the pressure measuring device.

Adhere to the safety notes and operating instructions which are given in the operating manual. Additionally applicable regulations

regarding occupational safety, accident preven-tion as well as national installation standards and engineer-ing rules must be complied

with!

This operating manual is part of the device, and should be kept nearest its location, always accessible to all employees.

This operating manual is copyrighted. The contents of this operating manual reflect the version available at the time of printing. It has

been issued to our best knowledge. Levelpro is not liable for any incorrect statements and their effects.

By non observance of the operating manual, inappropriate use, modification or damage, no liability is assumed and warranty claims will

be excluded.

1. GENERAL INFORMATION

1.1 Information on the Operating Manual

DANGER! – Dangerous Situation, which may result in death or serious injuries

WARNING! – Potentially Dangerous Situation, which may result in death or serious injuries

CAUTION! – Potentially Dangerous Situation, which may result in minor injuries

CAUTION! – Potentially Dangerous Situation, which may result in physical Damage

1.2 Symbols Used

1.3 Limitation of Liability

The Levelpro Level Sensors have been developed for continuous level measurement. It is the operator's responsibility to check and

verify the suitability of the device for the intended application. If any doubts remain, please contact our technical department in order to

ensure proper usage and compatibility . Levelpro is not liable for any incorrect selections and their effects!

1.4 Intended Use

NOTE : �ps and informa�on to ensure a failure-free opera�on

WARNING! To avoid operator hazards and damages of the device, the following instructions have to be worked out by

qualified technical personnel.

Continuous Submersible Level Transmitter

Levelpro-Sensors Manual
