Permissible media are liquids (no solids or frozen media), specified in the data sheet. In addition it has to be ensured, that this medium is
compatible with the any wetted parts of the level sensor.
The technical data listed in the current data sheet are engaging and must be complied with. If the data sheet is not available, please
order or download it from our homepage. (http://www.iconprocon.com)
Please verify that all listed parts are undamaged included in the delivery and check for consistency specified in your order:
1.5 Package contents
The device can be identified by its
manufacturing label.
WARNING! – Danger through improper usage!
Probe
Mounting Instructions
2. PRODUCT IDENTIFICATION
3.1 Mounting and safety instructions
3. MECHANICAL INSTALLATION
Fig. 1 Manufacturing Label
Input :
Type:
Code:
SN: 0143693
0 - 10 m WC
Output : 4-20mA 2-wire
Supply:
Vs+: Red
Connector Pinout:
Vs -: Black
Shield: Yellow-Green
12-36 VDC
pressure measurement
www. iconprocon.com
Nominal
Pressure Range
Signal
Supply
Type
Designation
Ordering
Code
Serial
Number
Cable Colours
WARNING! Install the device only when depressurized and not connected to power source!
WARNING! This device may only be installed by qualified technical personnel who has read and under stood the operating
manual!
Handle this high sensitive electronic precision measuring device with care, both in packed and unpacked condition!
There are no modifications/changes to be made on the device.
Do not throw the package/device!
To avoid damaging the diaphragm, remove packaging and protective cap directly before starting assembly.
The delivered protective cap has to be stored!
Place the Protective Cap on the pressure port again immediately after disassembling.
Handle the unprotected diaphragm very carefully - it is very sensitive and may be easily damaged.
Do not use any force when installing the device to prevent damage of the device and the plant!
W
hen placing the device into operation or after mainte nance work, the probe has to be submerged slowly into the medium!
A rough immersion into the medium can damage or destroy the diaphragm.
I
f there is any danger of damage by lightning or overpressure when the device is installed outdoor, we suggest putting a
sufficiently Sized overpressure protection device between the supply or switch cabinet and the device
Continuous Submersible Level Transmitter
Levelpro-Sensors Manual
02
© Icon Process Controls Ltd. All Rights Reserved
