LevelOne FCS-4201 - Technical Specifications

Network Camera User’s Manual
65/66
B. Technical specifications
- System
RAM : 4GB DDR
ROM : 16MB flash ROM
- Camera specification
Type 1/2.8 Sony CMOS sensor IMX222
Resolution: 1920x1080
- IR Led
Auto/Manual mode, 15~20M visible
Spectral band width 42nm, Peak emission wavelength
850nm
Daylight sensor, angle +/-65, wave length 400~700nm
- Lens
3X optical zoom lens, auto iris, auto focus
f = 3mm ~ 9mm, F1.8
Fov(D), 136° ~ 39°
- Protocol
TCP/IP, HTTP, SMTP, FTP, DDNS, UPnP, Telnet,
NTP, PPPoE, DNS, DHCP and RTSP
- Video Resolution
Up to 30 frames at 1920*1080, 1280x1024,
1280x800, 640x480, 320x240 and 176x144
- Audio
G.711/AMR/AAC,Omni-directional Microphone
Support 2 way audio
- Algorithm supported
H.264/MPEG4/MJPEG multi-codec for streaming
video
JPEG for still image
- Physical
10 baseT or 100 baseT Fast Ethernet auto
negotiation
- I/O Interface
RJ-45
DI
DO
Audio in
Audio out
DC Power
Micro SD slot(inside camera)
- Pan/Tilt angle
Support auto tracking function
Support multi - direction movement
Pan : 250°
Tilt : 75°
- Power
Input: 100-240VAC, 50/60Hz, 0.7A
Output: 12VDC, 1.5A
Consumption: Max 8 W
Support 802.3af compliant Power over Ethernet
- EMI & Safety
CE, FCC
- Dimension
Height : 69mm, Diameter : 92mm
- Operating Environment
Temperature : 0 ~ 40℃
Humidity : 85% RH
- Weight
NET. 380g(PTZ model)
NET. 370g(Fixed model)
