LevelOne KVM-0221 User Manual

12
5. Technical Specification
Model No. KVM-0221/0222 KVM-0421/0422
PC Port 2 4
PC Port Connector
(All Female Types)
VGA HDDB 15pin-F (integrated with USB interface)
Local Console Port
(All Female Types)
1 x USB Type A
1 x HDB 15-pin female
1 x 3.5 mm audio/mic jack (KVM-0221/0421)
PC selection HotKeys, Push Button, Software Utility
PC Port LED 2 (Green) 4 (Green)
Keyboard Emulation USB
Mouse Emulation USB
VGA Resolution 2048 x 1536
Housing Plastic
KVM Switch Power Type USB Interface Power
Operation Temperature 0~40℃
Storage Temperature -10 ~ 50℃
Humidity 0~80% RH Non-Condensing
Dimension (mm) 100(L) X 71.5(W) X 26 (H) 170(L) X 87(W) X 26 (H)

LevelOne KVM-0221 Specifications

General

Console ports	3.5mm headphone, 3.5mm mic, USB A, VGA (D-Sub)
Audio connections	Yes
Headphone outputs	1
USB connector type	Mini-USB, USB Type-A
USB 2.0 ports quantity	4
VGA (D-Sub) ports quantity	3
Number of computers controlled	2
Scan interval	25, 35, 45, 55, 50, 40, 10, 15, 20, 30, 60 s
Maximum resolution	2048 x 1536 pixels
Product color	Black, Green
Rack mounting	-
Housing material	Plastic
Built-in display	No
Country of origin	China
Harmonized System (HS) code	85176200
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 80 %
Cables included	KVM, Mini-USB
Package depth	76 mm
Package width	221 mm
Package height	190 mm
Package weight	1140 g

Weight and Dimensions

Depth	61 mm
Width	96 mm
Height	24 mm
Weight	116 g
