LevelOne KVM-0221 User Manual

instructions to completion. When installation is complete, a LevelOne icon will be on the
system tray of user’s desktop. For operation details of the KVM Switch utility, please
refer to the user manual for detail.
3. The Windows KVM Switch utility is recommended for use on Windows XP or later. The
Mac KVM Switch utility is recommended for use on Mac OS 10.4 or later.
Windows Mac OS
No live connection detected
Current active PC channel is on port 1
Current active PC channel is on port 2
The KVM Switch Utility supports both the Windows and the Mac OS operating systems. For
other OS platforms such as Linux, user can only use the keyboard hotkey – Scroll Lock +
Scroll Lock - to switch PC. However, this switching hotkey is not available on non-PC
platform such as Mac OS.
4. Connect the shared USB keyboard, USB mouse, D-Sub monitor, speaker/headphone
and microphone each to its port on the KVM Switch.
(Models KVM-0222 and KVM-0422 not support audio switching)
5. Connect each KVM PC port to a computer, using the slim 3-in-1 KVM combo cable and
the audio/MIC cable. Once the KVM Switch and computers connected properly, user
can now operate the KVM Switch immediately.
4

LevelOne KVM-0221 Specifications

General

Console ports	3.5mm headphone, 3.5mm mic, USB A, VGA (D-Sub)
Audio connections	Yes
Headphone outputs	1
USB connector type	Mini-USB, USB Type-A
USB 2.0 ports quantity	4
VGA (D-Sub) ports quantity	3
Number of computers controlled	2
Scan interval	25, 35, 45, 55, 50, 40, 10, 15, 20, 30, 60 s
Maximum resolution	2048 x 1536 pixels
Product color	Black, Green
Rack mounting	-
Housing material	Plastic
Built-in display	No
Country of origin	China
Harmonized System (HS) code	85176200
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 80 %
Cables included	KVM, Mini-USB
Package depth	76 mm
Package width	221 mm
Package height	190 mm
Package weight	1140 g

Weight and Dimensions

Depth	61 mm
Width	96 mm
Height	24 mm
Weight	116 g
