11a/b/g Wireless Multi-Client Bridge/AP/WDS Version 1.0
62
Appendix A – Specifications
Data Rates
1, 2, 5.5, 6, 9, 11, 12, 18,
24, 36, 48, 54 Mbps
Standards
IEEE802.11a/b/g,
IEEE802.3, IEEE802.3u,
IEEE802.3af, IEEE802.1f,
IEEE802.1x
Compatibility
IEEE 802.11g/ IEEE
802.11b
Power Requirements
Active Ethernet (Power
over Ethernet) –48
VDC/0.375A
External Unit: Auto
sensing 100/240 VAC;
50/60 Hz
Regulation Certifications
FCC Part 15/UL, ETSI
300/328/CE
RF Information
Frequency Band
802.11a: 5.15~5.25GHz,
5.25~5.35GHz,
5.47~5.725GHz,
5.725~5.825GHz
802.11b/g: U.S., Europe
and Japan product
covering 2.4 to 2.484 GHz,
programmable for
different country
regulations
Media Access Protocol
Carrier Sense Multiple
Access with Collision
Avoidance (CSMA/CA)
Modulation Technology
Orthogonal Frequency
Division Multiplexing
(OFDM)
DBPSK @ 1Mbps
DQPSK @2Mbps
CCK @ 5.5 & 11Mbps
BPSK @ 6 and 9 Mbps
QPSK @ 12 and 18 Mbps
16-QAM @ 24 and 36
Mbps
64-QAM @ 48 and 54
Mbps
Operating Channels
802.11b/g:
11 for North America, 14
for Japan, 13 for Europe,
802.11a:
US/Canada:12 non-
overlapping channel
(5.15~5.35GHz,
5.725~5.825GHz)
Europe:19 non-overlapping
channel (5.15~5.35GHz,
5.47~5.825GHz)
Japan: 4 non-overlapping
channel (5.15~5.25GHz)
China: 5 non-overlapping
channel (5.725~5.85GHz)
Receive Sensitivity (Typical)
• 5.15~5.85G(IEEE802.11a)
6Mbps@ -88dBm;
54Mbps@ -70dBm
• 2.412~2.472G(IEEE802.1
1g)
6Mbps@ -91dBm;
54Mbps@ -74dBm
• 2.412~2.472G(IEEE802.1
1b)
11Mbps@ -90dBm
1Mbps@ -95dBm
Available transmit power
(Typical)
• 5.15~5.24
GHz(IEEE802.11a)
17dBm @6 ~ 24Mbps
17dBm @36Mbps
16 dBm @48Mbps
15 dBm @54Mbps
• 5.26~5.35GHz(IEEE802.11
a)
20dBm @6 ~ 24Mbps
18dBm @36Mbps
16 dBm @48Mbps
15 dBm @54Mbps
• 5.745~5.85GHz
(IEEE802.11a)
18dBm @6 ~ 24Mbps
16dBm @36Mbps
14 dBm @48Mbps
13 dBm @54Mbps
• 2.412~2.472G(IEEE802.11
g)
26dBm @6 ~ 24Mbps
23dBm @36Mbps
22 dBm @48Mbps
21 dBm @54Mbps
• 2.412~2.472G(IEEE802.11
b)
up to 26 dBm. @1, 2, 5.5 and
11Mbps
RF Connector
SMA (Fr) Type
(Optional
for External Antenna use)
Networking
Topology
Ad-Hoc, Infrastructure
Operation Mode
Point-to-Point/ Point-to-
Multipoint Bridge/ AP/
Client Bridge/ WDS
Interface
Wireless IEEE802.11b/g
One 10/100 RJ-45 port
Security
z IEEE802.1x
Authenticator / RADIUS
Client (EAP-
MD5/TLS/TTLS)
Support in AP Mode
z WPA/WPA2 Supplicant
support in Client Bridge
Mode
z WPA /WPA2/ Pre Share
KEY (PSK) with
TKIP/AES
z MAC address filtering
(AP only)
z Hide SSID in beacons
IP Auto-configuration
DHCP client/server
Management
Configuration
Web-based configuration
(HTTP)
Firmware Upgrade
Upgrade firmware via
web-browser
Serial Interface (RS-232)
TFTP
Physical
Dimensions (HxWxD)
163.8(L)mm *
135.2(W)mm * 47.0(H)mm
Weight
1.2 Kg (2.6 lbs)
Environment
Temperature Range
Operating: -20°C to 60°
Storage: -40°Cto 80°
Humidity (non-condensing)
5%~95% Typical
