2. Interface Description
The WAN/POE port is used to connect to network devices, such
as a POE switch OR POE adapter.
The LAN port is used to connect to network devices, such as a
switch or PC
With the AP powered on, press the Reset button for 10 seconds
until the USB LED blink with green light and System LED on
without blink. The AP will restart itself and reset the device to
factory default settings.
To connect with USB storage device
12V/1.5A DC input Power Adapter .
(WAP-6117 Power Adapter unit is to be ordered separately)
