Statistics Screen
Click Statistics tab of the utility, the page will display the transmitted and received results.
Figure 6: Statistics Screen
Data - Statistics Screen
Transmit
Tx OK
Frames successfully sent.
Tx Error
Frames failed to transmit.
Receive
RX OK
Frames received successfully.
Rx Packet
Count
Frames received with packet count.
Rx Retry
Frames successfully received with one or more reties.
Rx ICV Error
Frames received with ICV error.
Reset
Click the button to reset counters to zero.
