WPS Screen
WPS (Wi-Fi Protected Setup) can simplify the process of connecting any device to the
wireless network by using the push button configuration (PBC) on the Wireless Access
Point, or entering a PIN code.
You will use the WPS screen when you try to connect the wireless network with the WPS
function.
Figure 7: WPS Screen
Data - WPS Screen
Pin Input config (PIN)
PIN Code
Enter the PIN code displayed in the screen to the WPS screen of
the access point.
PIN Input config
(PIN) Button
Click this button to connect to the selected network.
Push Button
Push Button
Start to add to AP using PBC configuration method.
After clicking the Push Button Config (PBC), press the physical
button or the visual button on the WPS screen of the access point.
