Leviton Decora Smart DG6HD - Wiring the Dimmer; Connecting Wires According to Diagram

9
1. Work on only one connection at a time.
2. Connect wires as shown.
3. Secure wire connections with an electrical connector.
Wire your dimmer
If your wall box looks different,
consult an electrician.
BK
YL/RD
RD
WH
HOT
GROUND
NEUTRAL
LOAD
