Leviton EVBL2 Series - Mounting Diagram

Mounting Diagram
A typical installation is shown below .
NOTE: Before installation or use of this product, review instructions carefully and consult with
a licensed contractor, electrician, or trained installation expert to ensure compliance with local
building codes and safety standards.
4
24" min.
READY
CHARGE
FAULT
Hook
(not supplied)
NEMA
6-30 Outlet
