6
EN
GETTING TO KNOW YOUR HUMIDIFIER
A
B
K
V
X
I
J
H
D
L
M
G
F
W
E
C
R
S
N
O
P
Q
Water tank, upside down
T
U
A. Nozzle
B. Water Tank Cover
C. Dust Cover
D. Mist Tube
E. Water Tank
F. Base
G. Control Knob
H. Max Water Line (Tank)
I. Water Tank Handles
J. Water Filter
K. Power Cord
L. Float
M. Float Brackets
N. Max Water Line (Base)
O. Secondary Float
P. Transducer
Q. Air Outlet
R. Air Inlet
S. Feet
T. Water Outlet Valve Assembly
U. Water Outlet Valve
V. Noise Silencer
W. Refill Indicator Light
X. Cleaning Brush
CONTROLS
Control Knob
• Rotate clockwise to turn on the
humidifier and to adjust the mist level.
• Rotate counterclockwise to turn o the
humidifier.
Refill Indicator Light
• The red light turns on when the water
tank is empty. Refill the water tank (see
page 8).
• The red light turns o when the water
tank is filled.
Note:
There is a clicking sound when the
humidifier turns on/o.
