LA: Character centering
This setting emulates certain Kyocera machines that center characters within the spacing. The factory default value is
1 (centering enabled).
To disable character-centering use: !R! FRPO LA,0; RES; EXIT;
If the placement of text appears to be wrong, then try changing this switch.
LB: Memorex font group
This setting allows the Memorex font group to be set.
The font groups are selected as follows:
FRPO LB parameter Font group
0 Original
1 A/B
2 C/D
3 E/F
4 G/H
5 I/J
6 K/L
For example, to select font group E/F, use: !R! FRPO LB,3; EXIT;
LC: Use bitmap fonts instead of outlines
This setting overrides the simulation of bitmap fonts if an actual bitmap version is resident. Currently, there are bitmap
versions for font 9 and font 28. Setting LC to 1 forces the printer to print font 9 and font 28 using the bitmap version.
The default setting of 0 forces font 9 and font 28 to be simulated with a scalable font.
LE: Paper source to apply LF/LG offsets
This allows offsetting of the logical page for pages that print from a particular paper source.
Notes:
• Do not use this setting if all paper sources need the same offset. Instead, use the FRPO L1-L8, R3, or A1-A8
parameters.
• This setting is useful for odd-sized papers.
• The LF and LG parameters designate the offset to be used. Only one source can be selected.
The sources are selected by setting the LE parameter as follows:
FRPO LE parameter Paper source
0 No source
1 Tray 1
2 Manual
3 Manual env
PRESCRIBE commands
16
