Repetitive defects guide
Page 1 of 2
Repetitive defects guide
Change transfer belt
27 mm (1.1 in.)
Change photodeveloper (black alone or all color)
94 mm (3.7 in.)
Change cartridge
60 mm (2.4 in.)
Replace fuser
140 mm (5.5 in.)
Match a set of repeating defects on
a print job to the marks on one of the
horizontal lines. The line that best
matches the defects on the print job
indicates the cause of the defect.
For example, the distance between these two
marks represents a repeating defect that occurs
every 45.1 mm. This means the cartridge needs
replacing.
Change cartrdige
45.1 mm (1.78 in.)
Change photodeveloper (black alone or all color)
31.5 mm (1.2 in.)
