Color quality guide
Page 7 of 7
To access the pages of Detailed Color Samples, use the printer Embedded Web Server interface. Select the Color
Samples option within the Configuration Menu. Nine color conversion table options and three buttons called Print,
Detailed, and Reset are shown on the options screen.
If the user selects a color conversion table and presses the Print button, the printer prints the default color
samples pages. If the user selects a color conversion table and presses the Detailed button, a new interface
becomes available. The interface lets the user enter individual R, G, and B values of the specific color of interest.
The user can also enter an increment value that defines the difference between the RGB value that each color
box differs by. If the user selects Print, a printout generates which consists of the user-specified color and the
colors that exist near this color based on the increment value.
This process can be duplicated for Cyan (C), Magenta (M), Yellow (Y), and Black (K) color conversion tables, too.
Collectively, these values are known as CMYK color. The default increment is 10 percent for Black, and 20 percent
for Cyan, Magenta, and Yellow. The increment value defined by the user for Detailed Color Samples applies to
Cyan, Magenta, Yellow, and Black.
