Use the To
6
Card reader light Check card reader status. The light blinks to indicate that a memory card is being
accessed.
7
Wi-Fi indicator Check wireless status.
8
Paper exit tray Hold paper as it exits.
9 Printer control panel Operate the printer.
10
Top cover Access the scanner glass.
11 Paper feed guard Prevent items from falling into the paper slot.
Use the To
1
Top cover Access the scanner glass.
2
Scanner glass Scan and copy photos and documents.
3
USB port Connect the printer to a computer using a USB cable.
Warning—Potential Damage: Do not touch the USB port except when plugging in or
removing a USB cable or installation cable.
4
Power supply with port Connect the printer to a power source.
5
Duplex unit
• Print on both sides of a sheet of paper.
• Remove paper jams.
6 Printhead Install, replace, or remove ink cartridges.
7
Scanner unit
• Access the ink cartridges and printhead.
• Remove paper jams.
About your printer
8
