Lexmark M3150 Service Manual

Option tray pick/lift motor service check
Action Yes No
Step 1
a Remove the option tray insert.
b Check the lift plate and gears for proper operation by moving
the metal plate.
Do the lift plate and gears move freely, and are they free of wear
or damage?
Go to step 2. Replace the tray
insert.
Step 2
Check the pick/lift motor for the following:
• Gear tooth breakage
• Freedom of rotation
Is it free of wear or damage?
Go to step 3. Replace the tray.
Step 3
Check the cable J11 on the option tray controller card.
Is it properly connected and free of damage?
Contact the next
level of support.
Replace the tray.
Option tray separator/pass through motor service check
Action Yes No
Step 1
a Remove the option tray insert.
b Check the separator roll assembly gear under the tray base for
the following:
• Gear tooth breakage
• Freedom of rotation
Does it move freely, and is it free of wear or damage?
Go to step 2. Replace the tray.
Step 2
Check the cable J10 on the option tray controller card.
Is it properly connected and free of damage?
Go to step 3. Replace the tray.
Step 3
Check the separator roll assembly for wear or damage.
Is it free of wear or damage?
Contact the next
level of support.
Replace the
separator roll
assembly. See
“Separator roll
assembly removal”
on page 320.
4514-6xx
Diagnostics and troubleshooting
162

Lexmark M3150 Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	47 ppm
Printing colors	Black
Maximum duty cycle	150000 pages per month
Recommended duty cycle	3000 - 16000 pages per month
Number of print cartridges	1
Paper input type	Paper tray
Total input capacity	650 sheets
Total output capacity	250 sheets
Maximum input capacity	2300 sheets
Multi-Purpose tray input capacity	100 sheets
Envelopes sizes	7 3/4, 9, 10, DL
Maximum print size	210 x 297 mm
Paper tray media types	Card stock, Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	-
Mobile printing technologies	Not supported
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Parallel, Serial (RS-232), Wireless LAN
USB 2.0 ports quantity	3
Processor model	2-Core
Processor frequency	800 MHz
Maximum internal memory	2560 MB
Sound pressure level (printing)	55 dB
Display	LCD
Control type	Touch
Product color	Black, White
Display diagonal	4.3 \
Power consumption (printing)	- W
Sustainability certificates	ENERGY STAR
Operating altitude	0 - 2896 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %

Weight and Dimensions

Depth	396.5 mm
Width	399 mm
Height	306 mm
