Troubleshooting
Printer scans the page, but image is not displayed on the
computer
Make sure that the IP address of your computer matches the IP address assigned to your network interface card.
1 Open a terminal window, and then type hostname. Press Enter.
2 Type ping [computer_hostname]. Press Enter, and then take note of the IP address listed.
3 Type /usr/lexscan/bin/lsinet, and then press Enter. Compare the IP address listed with the IP address
obtained in step 2.
If the IP addresses do not match, then do one the following:
Correct your /etc/hosts or DNS entries.
Update the SANE driver configuration file and specify the appropriate network interface to use.
For more information on how to correct /etc/hosts or DNS entries, see the documentation that came with your operating
system.
If the problem is not resolved, then see “Printer stops scanning or prints a 'Profile scan failed' page” on page 18.
Printer stops scanning or prints a “Profile scan failed” page
DISABLE ANY FIREWALL APPLICATION
To disable your firewall application, see the documentation that came with your operating system.
OPEN THE REQUIRED SCANNING PORTS (TCP: 9751-9760)
Open a terminal window, and then type # iptables -I INPUT -p tcp --dport 9751:9760 -j
ACCEPT -i eth0. Press Enter.
For most Linux distributions, you can open specific ports with the iptables command.
ACCEPT THE DEVICE CERTIFICATE
If there is an error verifying a security certificate before completing a scan, then accept the certificate to proceed.
You may accept the certificate for a single scan job or for all future scan jobs.
ENTER A VALID SCAN JOB LOGIN
If a 401 Unauthorized Error is received when sending a scan job to the printer, then you need to provide a
valid user name and password .
The user name and password combination is valid for a single scan job and all future scan jobs.
Troubleshooting
18

Other manuals for Lexmark M3150

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Lexmark M3150 and is the answer not in the manual?

Lexmark M3150 Specifications

General IconGeneral
ColorNo
Duplex printingYes
Print technologyLaser
Time to first page (black, normal)6.5 s
Print speed (black, normal quality, A4/US Letter)47 ppm
Printing colorsBlack
Maximum duty cycle150000 pages per month
Recommended duty cycle3000 - 16000 pages per month
Number of print cartridges1
Paper input typePaper tray
Total input capacity650 sheets
Total output capacity250 sheets
Maximum input capacity2300 sheets
Multi-Purpose tray input capacity100 sheets
Envelopes sizes7 3/4, 9, 10, DL
Maximum print size210 x 297 mm
Paper tray media typesCard stock, Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizesExecutive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Legal (media size)
ISO A-series sizes (A0...A9)A4, A5, A6
JIS B-series sizes (B0...B9)B5
Maximum ISO A-series paper sizeA4
Wi-Fi-
Mobile printing technologiesNot supported
Standard interfacesEthernet, USB 2.0
Optional connectivityParallel, Serial (RS-232), Wireless LAN
USB 2.0 ports quantity3
Processor model2-Core
Processor frequency800 MHz
Maximum internal memory2560 MB
Sound pressure level (printing)55 dB
DisplayLCD
Control typeTouch
Product colorBlack, White
Display diagonal4.3 \
Power consumption (printing)- W
Sustainability certificatesENERGY STAR
Operating altitude0 - 2896 m
Operating temperature (T-T)16 - 32 °C
Operating relative humidity (H-H)8 - 80 %
Weight and Dimensions IconWeight and Dimensions
Depth396.5 mm
Width399 mm
Height306 mm
