Lexmark MS417dn User Manual

PCL Emul menu
Use To
Font Source
Resident
Download
Flash
All
Specify the set of fonts used by the Font Name menu.
Notes:
• Resident is the factory default setting. This shows the factory default
set of fonts downloaded in the RAM.
• Download shows all the fonts downloaded in the RAM.
• Flash shows all fonts resident in that option. The optional flash
memory card must be properly formatted and cannot be read/write‑,
write‑, or password‑protected.
• All shows the fonts available to any option.
Font Name
Courier 10
Identify a specific font and the option where it is stored.
Note: Courier 10 is the factory default setting. Courier 10 shows the font
name, font ID, and the storage location in the printer. The font source
abbreviation is R for Resident, F for Flash, and D for Download.
Symbol Set
10U PC‑8
12U PC‑850
Specify the symbol set for each font name.
Notes:
• 10U PC‑8 is the U.S. factory default setting. 12U PC‑850 is the
international factory default setting.
• A symbol set is a set of alphabetic and numeric characters,
punctuation, and special symbols. Symbol sets support the dierent
languages or specific program, such as math symbols for scientific
text. Only the supported symbol sets are shown.
PCL Emulation Settings
Point Size
1.00–1008.00
Change the point size for scalable typographic fonts.
Notes:
• 12 is the factory default setting.
• Point size refers to the height of the characters in the font. One point
equals approximately 0.014 inch.
• Point sizes can be increased or decreased in 0.25‑point increments.
PCL Emulation Settings
Pitch
0.08–100
Specify the font pitch for scalable monospaced fonts.
Notes:
• 10 is the factory default setting.
• Pitch refers to the number of fixed‑space characters per inch (cpi).
• Pitch can be increased or decreased in 0.01‑cpi increments.
• For non‑scalable monospaced fonts, the pitch appears on the
display but it cannot be changed.
PCL Emulation Settings
Orientation
Portrait
Landscape
Specify the orientation of text and graphics on the page.
Notes:
• Portrait is the factory default setting. Portrait prints text and graphics
parallel to the short edge of the page.
• Landscape prints text and graphics parallel to the long edge of the
page.
Understanding the printer menus 120

Lexmark MS417dn Specifications

General

Display	LCD
Certification	ICES-003 Class B, Class B BSMI VCCI class B, FDA, UL 60950-1, FCC Class B, CUL CAN / CSA-C22.2 60950-1, NOM CB EN / IEC 60950-1, CB EN / IEC 60825-1, CE DoC (EN 62301 Class B, EN 62311, EN CE / IEC 60950-1, CE EN / IEC 60825-1, EN 61000-3, EN 55022 Class B, EUP, EN 55024, UL) EFTA (CE), KCC, CCC, CECP, CEL, C-tick DoC, UL-AR, KC mark, UL GS mark, EC 1275, MET-I, ISO 532b ECMA-370, TED, GOST, SII, TER
Color display	Yes
Product color	White
Display diagonal	2.4 \
Color	No
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	16 ppm
Maximum duty cycle	100000 pages per month
Recommended duty cycle	750 - 7200 pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PDF 1.7, PPDS, PostScript 3, XPS
Average cartridge yield (black)	2500 pages
Maximum cartridge yield (black)	8500 pages
Power consumption (ready)	3 W
Power consumption (standby)	7 W
Power consumption (printing)	560 W
Energy Star Typical Electricity Consumption (TEC)	1.8 kWh/week
Noise level (ready)	15 dB
Maximum internal memory	256 MB
Sound pressure level (printing)	54 dB
Sound pressure level (quiet mode)	50 dB
Sustainability certificates	ENERGY STAR
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	850 sheets
Total number of input trays	2
Maximum number of input trays	3
Multi-Purpose tray input capacity	50 sheets
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Linux operating systems supported	Debian 5.0, Debian 6.0, Fedora 16, Fedora 17, Fedora 18, Linux Mint 10, Linux Mint 11, Linux Mint 12, Linux Mint 13, PCLinuxOS 2011, Red Flag Desktop 6.0, Red Hat Enterprise Linux WS 4.0, Red Hat Enterprise Linux WS 6.0, SUSE Linux Enterprise Desktop 11, Ubuntu 11.04, Ubuntu 11.10, Ubuntu 12.04, Ubuntu 12.10, openSUSE 11.3, openSUSE 11.4, openSUSE 12.1, openSUSE 12.2
Other operating systems supported	IBM AIX 5.3, IBM AIX 6.1, IBM AIX 7.1, Novell NetWare 6.x, Novell Open Enterprise Server, Solaris 10, Solaris 11
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows RT, Windows RT 8.1, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Operating altitude	0 - 2896 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Envelopes sizes	7 3/4, 9, 10, DL
Paper tray media types	Card stock, Envelopes, Labels, Plain paper, Transparencies
Paper tray media weight	60 - 90 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Package depth	472 mm
Package width	432 mm
Package height	380 mm
Package weight	16000 g
Cabling technology	10/100/1000Base-T(X)
Security algorithms	IPSec, LEAP, MD5, MSCHAPv2, PEAP, SNMPv3, SSL/TLS, TTLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	-
Supported network protocols (IPv4)	TCP/IP, AppleTalk
Supported network protocols (IPv6)	TCP/IP, TCP, UDP
Cables included	AC
USB connector	USB Type-B
Standard interfaces	Ethernet, Parallel, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet interface type	Gigabit Ethernet
Scalability	1S
Intel® Turbo Boost Technology	1.0
Thermal solution specification	PCA 2013D
CD read speed	- x

Weight and Dimensions

Depth	382 mm
Width	399 mm
Height	263 mm
