Lexmark MS417dn User Manual

Notes:
• View the printer IP address in the TCP/IP section in the Network/Ports menu. The IP address appears
as four sets of numbers separated by periods, such as 123.123.123.123.
• If you are using a proxy server, then temporarily disable it to load the Web page correctly.
2 Click Settings > Print Settings > Supply
Notifications
.
3 From the drop‑down menu for each supply, select one of the following
notification
options:
Notification Description
O The normal printer behavior for all supplies occurs.
SNMP Only The printer generates a simple network management protocol (SNMP) alert when the
supply condition is reached. The status of the supply will appear on the menus page
and status page.
E‑mail Only The printer generates an e-mail when the supply condition is reached. The status of
the supply will appear on the menus page and status page.
Warning The printer displays the warning message and generates an e‑mail about the status
of the supply. The printer does not stop when the supply condition is reached.
Continuable Stop
1
The printer stops processing jobs when the supply condition is reached, and the user
needs to press a button to continue printing.
Non Continuable Stop
1,2
The printer stops when the supply condition is reached. The supply must be replaced
to continue printing.
1
The printer generates an e-mail about the status of the supply when supply notification is enabled.
2
The printer stops when some supplies become empty to prevent damage.
4 Click Submit.
MS312 and MS317 printer management
Accessing the remote control panel
The remote control panel on your computer screen lets you interact with the printer control panel, even when
you are not physically near the network printer. From your screen, you can view the printer status and do print-
related tasks.
1 Open a Web browser, and then type the printer IP address in the address
field.
Notes:
• Print a network setup page or menu settings page, and then locate the IP address in the TCP/IP
section. The IP address appears as four sets of numbers separated by periods, such as
123.123.123.123.
• If you are using a proxy server, then temporarily disable it to load the Web page correctly.
2 Press Enter to open the Web page of your printer.
3 Click Remote Operator Panel > Run Remote Panel.
Note: The remote control panel requires a Java plug‑in to launch.
Managing the printer 62

Lexmark MS417dn Specifications

General

Display	LCD
Certification	ICES-003 Class B, Class B BSMI VCCI class B, FDA, UL 60950-1, FCC Class B, CUL CAN / CSA-C22.2 60950-1, NOM CB EN / IEC 60950-1, CB EN / IEC 60825-1, CE DoC (EN 62301 Class B, EN 62311, EN CE / IEC 60950-1, CE EN / IEC 60825-1, EN 61000-3, EN 55022 Class B, EUP, EN 55024, UL) EFTA (CE), KCC, CCC, CECP, CEL, C-tick DoC, UL-AR, KC mark, UL GS mark, EC 1275, MET-I, ISO 532b ECMA-370, TED, GOST, SII, TER
Color display	Yes
Product color	White
Display diagonal	2.4 \
Color	No
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	16 ppm
Maximum duty cycle	100000 pages per month
Recommended duty cycle	750 - 7200 pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PDF 1.7, PPDS, PostScript 3, XPS
Average cartridge yield (black)	2500 pages
Maximum cartridge yield (black)	8500 pages
Power consumption (ready)	3 W
Power consumption (standby)	7 W
Power consumption (printing)	560 W
Energy Star Typical Electricity Consumption (TEC)	1.8 kWh/week
Noise level (ready)	15 dB
Maximum internal memory	256 MB
Sound pressure level (printing)	54 dB
Sound pressure level (quiet mode)	50 dB
Sustainability certificates	ENERGY STAR
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	850 sheets
Total number of input trays	2
Maximum number of input trays	3
Multi-Purpose tray input capacity	50 sheets
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Linux operating systems supported	Debian 5.0, Debian 6.0, Fedora 16, Fedora 17, Fedora 18, Linux Mint 10, Linux Mint 11, Linux Mint 12, Linux Mint 13, PCLinuxOS 2011, Red Flag Desktop 6.0, Red Hat Enterprise Linux WS 4.0, Red Hat Enterprise Linux WS 6.0, SUSE Linux Enterprise Desktop 11, Ubuntu 11.04, Ubuntu 11.10, Ubuntu 12.04, Ubuntu 12.10, openSUSE 11.3, openSUSE 11.4, openSUSE 12.1, openSUSE 12.2
Other operating systems supported	IBM AIX 5.3, IBM AIX 6.1, IBM AIX 7.1, Novell NetWare 6.x, Novell Open Enterprise Server, Solaris 10, Solaris 11
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows RT, Windows RT 8.1, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Operating altitude	0 - 2896 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Envelopes sizes	7 3/4, 9, 10, DL
Paper tray media types	Card stock, Envelopes, Labels, Plain paper, Transparencies
Paper tray media weight	60 - 90 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Package depth	472 mm
Package width	432 mm
Package height	380 mm
Package weight	16000 g
Cabling technology	10/100/1000Base-T(X)
Security algorithms	IPSec, LEAP, MD5, MSCHAPv2, PEAP, SNMPv3, SSL/TLS, TTLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	-
Supported network protocols (IPv4)	TCP/IP, AppleTalk
Supported network protocols (IPv6)	TCP/IP, TCP, UDP
Cables included	AC
USB connector	USB Type-B
Standard interfaces	Ethernet, Parallel, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet interface type	Gigabit Ethernet
Scalability	1S
Intel® Turbo Boost Technology	1.0
Thermal solution specification	PCA 2013D
CD read speed	- x

Weight and Dimensions

Depth	382 mm
Width	399 mm
Height	263 mm
