Lexmark MS521 Service Manual

230 paper jams
230 paper jam messages
Error code Description Action
230.03 Paper fed from the MPF never reached the sensor
(duplex).
See
“Sensor (duplex) jam at leading edge
service check” on page 90.
230.05 Paper fed from the MPF never cleared the sensor
(duplex).
See
“Sensor (duplex) jam at trailing edge service
check” on page 92.
230.13 Paper fed from tray 1 never reached the sensor
(duplex).
See
“Sensor (duplex) jam at leading edge
service check” on page 90.
230.15 Paper fed from tray 1 never cleared the sensor
(duplex).
See
“Sensor (duplex) jam at trailing edge service
check” on page 92.
230.23 Paper fed from tray 2 never reached the sensor
(duplex).
See
“Sensor (duplex) jam at leading edge
service check” on page 90.
230.25 Paper fed from tray 2 never cleared the sensor
(duplex).
See
“Sensor (duplex) jam at trailing edge service
check” on page 92.
230.33 Paper fed from tray 3 never reached the sensor
(duplex).
See
“Sensor (duplex) jam at leading edge
service check” on page 90.
230.35 Paper fed from tray 3 never cleared the sensor
(duplex).
See
“Sensor (duplex) jam at trailing edge service
check” on page 92.
230.43 Paper fed from tray 4 never reached the sensor
(duplex).
See
“Sensor (duplex) jam at leading edge
service check” on page 90.
230.45 Paper fed from tray 4 never cleared the sensor
(duplex).
See
“Sensor (duplex) jam at trailing edge service
check” on page 92.
230.91 Paper remains detected at the sensor (duplex)
after the printer is turned on.
See
“Sensor (duplex) static jam service check”
on page 93.
Sensor (duplex) jam at leading edge service check
Action Yes No
Step 1
Make sure that the paper is loaded properly. Use the
recommended paper. See
“Avoiding jams” on page 66.
Does the problem remain?
Go to step 2. The problem is
solved.
Step 2
a Enter the Diagnostics menu, and then navigate to:
Input tray quick print
b Do feed tests from dierent trays. Check if the same error
occurs.
Does the same problem remain?
Go to step 3. Perform the
appropriate service
check for the
specific
error.
4600-830, -835, -895
Diagnostics and troubleshooting
90

Lexmark MS521 Specifications

General

Print Technology	Monochrome Laser
Print Speed	Up to 46 ppm
Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 120, 000 pages
Processor Speed	1 GHz
Standard Output Capacity	250 sheets
Operating System Compatibility	Windows, Mac OS, Linux
Hard Drive	Optional
Recommended Monthly Page Volume	2000 - 15000 pages
Duplex Printing	Standard
Connectivity	USB, Ethernet
Media Types Supported	Paper Labels, Card Stock, Envelopes, Plain Paper, Transparencies
