Lexmark MS812dn Manual

Glossary
accepting
The state of a print queue when it allows the submission of new print jobs.
If a queue is in the accepting state, the user is able to use the lp or lpr
command to submit printer requests.
AIX
IBM's version of the UNIX operating system.
alias
A part of the BSD printer subsystem, aliases let you create multiple names for
the same print queue.
Automatic Printer Language
A printer language option for printers that support both PostScript and PCL
emulation printer languages. This option gives users the ability to print
PostScript, PCL emulation, and ASCII text files to the same print queue.
baud rate
The transmission speed of the serial communication. The sending device speed
must match the receiving port speed.
BPP device
A designation for Sun's bidirectional parallel port.
This type of destination usually has a device name that resembles /dev.bppxx,
replacing xx with the appropriate device number.
community name See SNMP community name.
disabled
The state of a print queue when print jobs are held in the print queue.
DNS See Domain Name System.
Domain Name System (DNS)
Something that resolves IP addresses to hostnames
enabled
The state of a print queue when print jobs are sent from the print queue to the
printer.
external print server
Hardware used to connect printers to a LAN using either a Token-Ring or
Ethernet cable.
The external print server allows network connectivity of a parallel or serial
printer.
firmware
Software that resides in the print server; also called microcode.
firmware level
The version of the firmware.
gateway
The connection device between the LAN and other equipment, such as
computers.
hostname
Name used to identify a network printer or computer.
internal print server
A card installed inside a printer to connect the printer to the network.
Internet Protocol (IP)
A standard protocol that specifies how packets are passed through networks.
It identifies the format of the packet and describes how it should be delivered
in a seamless manner. Although it is a separate protocol from TCP, it is often
referred to as TCP/IP because TCP and IP protocols are often used together.
IP address
The unique physical address of the printer on a network using TCP/IP protocol.
LAN See Local Area Network.
LAN segment
Any portion of a LAN that operates independently of, but is connected to, the
network by bridges or routers.
44

Lexmark MS812dn Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	4 s
Print margins (top, bottom, right, left)	4.2 mm
Print speed (black, normal quality, A4/US Letter)	66 ppm
Duplex print speed (black, normal quality, A4/US Letter)	40 ppm
Security algorithms	802.1x RADIUS, EAP-TLS, EAP-TTLS, LEAP, MD5, PEAP
Supported network protocols (IPv4)	TCP, UDP, AppleTalk, LPR/LPD, Direct IP, FTP, TFTP, ThinPrint, IPP
Printing colors	Black
Country of origin	China
Maximum duty cycle	300000 pages per month
Recommended duty cycle	5000 - 50000 pages per month
Number of print cartridges	1
Page description languages	Microsoft XPS, PCL 5e, PCL 6, PDF 1.7, PostScript 3, PPDS, XHTML
Maximum internal memory	2560 MB
Sound power level (standby)	32 dB
Sound pressure level (printing)	58 dB
Sound pressure level (quiet mode)	53 dB
Total input capacity	550 sheets
Maximum input capacity	4400 sheets
Total number of input trays	2
Maximum number of input trays	6
Multi-Purpose tray input capacity	100 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Maximum print size	216 x 356 mm
Paper tray media types	Card stock, Envelopes, Labels, Plain paper
Paper tray media weight	60 - 176 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Standard interfaces	USB 2.0
Optional connectivity	Parallel, Serial (RS-232), Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Other operating systems supported	Novell NetWare 5.x, Novell NetWare 6.x, Novell Open Enterprise Server
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Power consumption (off)	0.5 W
Power consumption (standby)	4.1 W
Power consumption (printing)	830 W
Package weight	27430 g
Networking features	Gigabit Ethernet
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Compatible operating systems	Windows XP (32/64bit)\\r Windows Vista (32/64bit)\\r Windows 7 (32/64bit)\\r Mac OS X 10.5, 10.6, 10.7, 10.8\\r SUSE Linux Enterprise Server 10, 11\\r SUSE Linux Enterprise Desktop 10, 11\\r Red Flag Linux Desktop 6.0\\r Linpus Linux Desktop 9.6\\r Debian GNU/Linux 5.0, 6.0\\r Red Hat Enterprise Linux WS 4.0, 5.0, 6.0\\r Ubuntu Linux 11.04, 11.10, 12.04\\r openSUSE Linux 11.3, 11.4, 12.1\\r PCLinuxOS 2011.9\\r Mint Linux 9, 10, 11, 12\\r Fedora Linux 14, 15\\r Unix Sun Solaris SPARC 9, 10\\r Unix HP-UX 11.11, 11.23, 11.31\\r Unix Sun Solaris x86 10, 11\\r Unix IBM AIX 5.3, 6.1, 7.1
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Sustainability certificates	ENERGY STAR
Display	LCD
Certification	RAL-UZ, CAN/CSA, ICES, BSMI, CNS, VCCI, FCC, UL, IEC, CE, CB, GS (TÜV), SEMKO, C-tick, CCC, CISPIR, EK, ECMA, TED
Product color	Grey, White
Operating altitude	0 - 2896 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	425 x 510 x 419 mm
