Lexmark MS812dn Technical Reference Manual

Overview
12
3
Overview
With the Forms and Bar Code Card installed, you can specify bar codes for printing in PCL 5 using
the following techniques:
1 Standard PCL 5 font selection commands (used in the HP BarDIMM Pro products)
2 Special Lexmark advanced PCL 5 commands for bar codes
Cursor positioning
Cursor positioning is set as follows when printing with the Forms and Bar Code Card:
• From the current cursor position, bar code printing begins at the bottom left corner of the left
bar.
• The cursor is located at the bottom right corner of the right bar when printing is complete.
• This cursor positioning applies with or without human-readable text.
Human-readable text
One-dimensional symbologies
Human-readable text can be specified with the bar codes.
Six different fonts are available for most human-readable text. See the Esc(s#H command in the
table “PCL 5 emulation escape sequences” on page 20.
The specified text can be automatically centered on the bar code, and scaled based on the width and
height of the bar code and the method of embedding.
Two-dimensional symbologies
Two-dimensional bar codes can encode thousands of characters, rendering human-readable
interpretation of the data impractical. Alternately, descriptive text, rather than literal text, may be
printed along with the symbol. If printed, any character size and font available may be selected, and
the text may be printed anywhere near the symbol. The text must not interfere with the bar code
symbol or its quiet zones.

Lexmark MS812dn Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	4 s
Print margins (top, bottom, right, left)	4.2 mm
Print speed (black, normal quality, A4/US Letter)	66 ppm
Duplex print speed (black, normal quality, A4/US Letter)	40 ppm
Security algorithms	802.1x RADIUS, EAP-TLS, EAP-TTLS, LEAP, MD5, PEAP
Supported network protocols (IPv4)	TCP, UDP, AppleTalk, LPR/LPD, Direct IP, FTP, TFTP, ThinPrint, IPP
Printing colors	Black
Country of origin	China
Maximum duty cycle	300000 pages per month
Recommended duty cycle	5000 - 50000 pages per month
Number of print cartridges	1
Page description languages	Microsoft XPS, PCL 5e, PCL 6, PDF 1.7, PostScript 3, PPDS, XHTML
Maximum internal memory	2560 MB
Sound power level (standby)	32 dB
Sound pressure level (printing)	58 dB
Sound pressure level (quiet mode)	53 dB
Total input capacity	550 sheets
Maximum input capacity	4400 sheets
Total number of input trays	2
Maximum number of input trays	6
Multi-Purpose tray input capacity	100 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Maximum print size	216 x 356 mm
Paper tray media types	Card stock, Envelopes, Labels, Plain paper
Paper tray media weight	60 - 176 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Standard interfaces	USB 2.0
Optional connectivity	Parallel, Serial (RS-232), Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Other operating systems supported	Novell NetWare 5.x, Novell NetWare 6.x, Novell Open Enterprise Server
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Power consumption (off)	0.5 W
Power consumption (standby)	4.1 W
Power consumption (printing)	830 W
Package weight	27430 g
Networking features	Gigabit Ethernet
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Compatible operating systems	Windows XP (32/64bit)\\r Windows Vista (32/64bit)\\r Windows 7 (32/64bit)\\r Mac OS X 10.5, 10.6, 10.7, 10.8\\r SUSE Linux Enterprise Server 10, 11\\r SUSE Linux Enterprise Desktop 10, 11\\r Red Flag Linux Desktop 6.0\\r Linpus Linux Desktop 9.6\\r Debian GNU/Linux 5.0, 6.0\\r Red Hat Enterprise Linux WS 4.0, 5.0, 6.0\\r Ubuntu Linux 11.04, 11.10, 12.04\\r openSUSE Linux 11.3, 11.4, 12.1\\r PCLinuxOS 2011.9\\r Mint Linux 9, 10, 11, 12\\r Fedora Linux 14, 15\\r Unix Sun Solaris SPARC 9, 10\\r Unix HP-UX 11.11, 11.23, 11.31\\r Unix Sun Solaris x86 10, 11\\r Unix IBM AIX 5.3, 6.1, 7.1
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Sustainability certificates	ENERGY STAR
Display	LCD
Certification	RAL-UZ, CAN/CSA, ICES, BSMI, CNS, VCCI, FCC, UL, IEC, CE, CB, GS (TÜV), SEMKO, C-tick, CCC, CISPIR, EK, ECMA, TED
Product color	Grey, White
Operating altitude	0 - 2896 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	425 x 510 x 419 mm
