Lexmark MS812dn Technical Reference Manual

Supported bar codes
137
Singapore 4-State
Bar Code for
Customer Encoding
YYYYYYY
2
This is identical to RM4SCC except for rules about
specific postcode data that can be encoded.
Swiss Post 3 of 9
bar code
YYYYYYY
2
This is a special version of Code 128C which
encodes an 18-digit identification code, composed
of a 2-digit post code, a 2-digit billing district code, a
6-digit customer account number, and an 8-digit
item number.
USPS FIM (Face
Identification
Marking)
YYYYYYY FIM is used by the United States Postal Service
(USPS) canceling machines to sort mail according
to its postage requirements and whether it is
bar-coded.
There are four types of FIM called FIM A, FIM B,
FIM C, and FIM D.
Bar code name
Lexmark Forms and Bar Code Card v3.0 Lexmark Forms and Bar Code Card v3.1 Lexmark Forms and Bar Code Card v3.2 Lexmark Forms and Bar Code Card v3.3 LDSS Forms  Composer  v3.3.9 LDSS  Document  Producer Lexmark Optra Forms
Sample image Comments
1 PDF417 and MaxiCode can be printed using Optra Forms only when the bar code option is also installed in the printer, and when the accompanying bar code dictionaries
have been installed in Optra Forms.
2 All one-dimensional bar code symbologies supported by the Bar Code Card version 2.4 or later can be printed with Optra Forms
when the bar code option is installed in
the printer, and the accompanying bar code dictionaries is installed in Optra Forms.
3 These bar codes are not available in PCL 5 or PostScript.

Lexmark MS812dn Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	4 s
Print margins (top, bottom, right, left)	4.2 mm
Print speed (black, normal quality, A4/US Letter)	66 ppm
Duplex print speed (black, normal quality, A4/US Letter)	40 ppm
Security algorithms	802.1x RADIUS, EAP-TLS, EAP-TTLS, LEAP, MD5, PEAP
Supported network protocols (IPv4)	TCP, UDP, AppleTalk, LPR/LPD, Direct IP, FTP, TFTP, ThinPrint, IPP
Printing colors	Black
Country of origin	China
Maximum duty cycle	300000 pages per month
Recommended duty cycle	5000 - 50000 pages per month
Number of print cartridges	1
Page description languages	Microsoft XPS, PCL 5e, PCL 6, PDF 1.7, PostScript 3, PPDS, XHTML
Maximum internal memory	2560 MB
Sound power level (standby)	32 dB
Sound pressure level (printing)	58 dB
Sound pressure level (quiet mode)	53 dB
Total input capacity	550 sheets
Maximum input capacity	4400 sheets
Total number of input trays	2
Maximum number of input trays	6
Multi-Purpose tray input capacity	100 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Maximum print size	216 x 356 mm
Paper tray media types	Card stock, Envelopes, Labels, Plain paper
Paper tray media weight	60 - 176 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Standard interfaces	USB 2.0
Optional connectivity	Parallel, Serial (RS-232), Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Other operating systems supported	Novell NetWare 5.x, Novell NetWare 6.x, Novell Open Enterprise Server
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Power consumption (off)	0.5 W
Power consumption (standby)	4.1 W
Power consumption (printing)	830 W
Package weight	27430 g
Networking features	Gigabit Ethernet
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Compatible operating systems	Windows XP (32/64bit)\\r Windows Vista (32/64bit)\\r Windows 7 (32/64bit)\\r Mac OS X 10.5, 10.6, 10.7, 10.8\\r SUSE Linux Enterprise Server 10, 11\\r SUSE Linux Enterprise Desktop 10, 11\\r Red Flag Linux Desktop 6.0\\r Linpus Linux Desktop 9.6\\r Debian GNU/Linux 5.0, 6.0\\r Red Hat Enterprise Linux WS 4.0, 5.0, 6.0\\r Ubuntu Linux 11.04, 11.10, 12.04\\r openSUSE Linux 11.3, 11.4, 12.1\\r PCLinuxOS 2011.9\\r Mint Linux 9, 10, 11, 12\\r Fedora Linux 14, 15\\r Unix Sun Solaris SPARC 9, 10\\r Unix HP-UX 11.11, 11.23, 11.31\\r Unix Sun Solaris x86 10, 11\\r Unix IBM AIX 5.3, 6.1, 7.1
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Sustainability certificates	ENERGY STAR
Display	LCD
Certification	RAL-UZ, CAN/CSA, ICES, BSMI, CNS, VCCI, FCC, UL, IEC, CE, CB, GS (TÜV), SEMKO, C-tick, CCC, CISPIR, EK, ECMA, TED
Product color	Grey, White
Operating altitude	0 - 2896 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	425 x 510 x 419 mm
