Lexmark MS812dn Technical Reference Manual

One-dimensional bar codes
21
Esc
(s#V
or
AEC
)s#V
Selects the height of the bar in points (1/72 inch).
Except in symbologies where #V is a fixed value, the bar height can be varied from a
minimum of 3 points (0.04 inch, 1 mm) to a maximum of 960 points (13.33 inch, 33
cm).
Example:
Esc
(s36v24750T
Selects the Codabar symbology with a bar height of 0.5 inch. Since parameters p, b,
s, and h are not specified, their values default to:
p
b1, s1
b2, s2
h
Do not print text
0.01 inch
0.03 inch
Not applicable because of #p parameter value
Esc
(s#1,#2,#3,#4B
or
AEC
)s#1,#2,#3,#4B
Selects bar widths in dots (1/600 inch).
Some bar codes require only two values for this command. Others require all four
values.
1 =
2 =
3 =
4 =
First (narrowest) width
Second width
Third width
Fourth width
Example:
Esc
(s3,9b24640T
Selects the Interleaved 2 of 5 symbology with narrow bars 3 dots wide, and wide
bars 9 dots wide. Since parameters v, p, s, and h are not specified, their values
default to:
v
p
s1
s2
h
0.4
Do not print text
0.01 inch
0.03 inch
Not applicable because of #p parameter value
Esc
(s#1,#2,#3,#4S
or
AEC
)s#1,#2,#3,#4S
Selects space widths in dots (1/600 inch).
Some bar codes, such as Interleaved 2 of 5 and Code 3 of 9, require only two values
for this command. Others, such as UPC, EAN and Code 128, require all four values.
1 =
2 =
3 =
4 =
First (narrowest) width
Second width
Third width
Fourth width
Example:
Esc
(s4p8,16,24,32s8,16,24,32b24700T
Selects Code 128 autoswitch with text printed under the bar code, space widths set
to 8, 16, 24, and 32 dots, and bar widths set to 8, 16, 24, and 32 dots. Since
parameters v and h are not specified, their values default to:
v
h
0.4
Automatically sized Courier Bold
Command Function/Parameters

Lexmark MS812dn Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	4 s
Print margins (top, bottom, right, left)	4.2 mm
Print speed (black, normal quality, A4/US Letter)	66 ppm
Duplex print speed (black, normal quality, A4/US Letter)	40 ppm
Security algorithms	802.1x RADIUS, EAP-TLS, EAP-TTLS, LEAP, MD5, PEAP
Supported network protocols (IPv4)	TCP, UDP, AppleTalk, LPR/LPD, Direct IP, FTP, TFTP, ThinPrint, IPP
Printing colors	Black
Country of origin	China
Maximum duty cycle	300000 pages per month
Recommended duty cycle	5000 - 50000 pages per month
Number of print cartridges	1
Page description languages	Microsoft XPS, PCL 5e, PCL 6, PDF 1.7, PostScript 3, PPDS, XHTML
Maximum internal memory	2560 MB
Sound power level (standby)	32 dB
Sound pressure level (printing)	58 dB
Sound pressure level (quiet mode)	53 dB
Total input capacity	550 sheets
Maximum input capacity	4400 sheets
Total number of input trays	2
Maximum number of input trays	6
Multi-Purpose tray input capacity	100 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Maximum print size	216 x 356 mm
Paper tray media types	Card stock, Envelopes, Labels, Plain paper
Paper tray media weight	60 - 176 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Standard interfaces	USB 2.0
Optional connectivity	Parallel, Serial (RS-232), Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Other operating systems supported	Novell NetWare 5.x, Novell NetWare 6.x, Novell Open Enterprise Server
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Power consumption (off)	0.5 W
Power consumption (standby)	4.1 W
Power consumption (printing)	830 W
Package weight	27430 g
Networking features	Gigabit Ethernet
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Compatible operating systems	Windows XP (32/64bit)\\r Windows Vista (32/64bit)\\r Windows 7 (32/64bit)\\r Mac OS X 10.5, 10.6, 10.7, 10.8\\r SUSE Linux Enterprise Server 10, 11\\r SUSE Linux Enterprise Desktop 10, 11\\r Red Flag Linux Desktop 6.0\\r Linpus Linux Desktop 9.6\\r Debian GNU/Linux 5.0, 6.0\\r Red Hat Enterprise Linux WS 4.0, 5.0, 6.0\\r Ubuntu Linux 11.04, 11.10, 12.04\\r openSUSE Linux 11.3, 11.4, 12.1\\r PCLinuxOS 2011.9\\r Mint Linux 9, 10, 11, 12\\r Fedora Linux 14, 15\\r Unix Sun Solaris SPARC 9, 10\\r Unix HP-UX 11.11, 11.23, 11.31\\r Unix Sun Solaris x86 10, 11\\r Unix IBM AIX 5.3, 6.1, 7.1
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Sustainability certificates	ENERGY STAR
Display	LCD
Certification	RAL-UZ, CAN/CSA, ICES, BSMI, CNS, VCCI, FCC, UL, IEC, CE, CB, GS (TÜV), SEMKO, C-tick, CCC, CISPIR, EK, ECMA, TED
Product color	Grey, White
Operating altitude	0 - 2896 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	425 x 510 x 419 mm
