Lexmark MS812dn Technical Reference Manual

Two-dimensional bar codes
56
Note: Byte Compaction Mode is sometimes referred to as Binary Compaction Mode.
Symbology ID bytes 1 and 2: (Required = 0001x)
These two bytes signify the symbology. Since most descriptors have different sizes and information,
all bar code descriptors must reserve the first two bytes for the symbology ID so the remaining bytes
can be interpreted accordingly. For PDF417, these two bytes must be 00x and 01x.
6–7 Y
dimension
byte 1 (in
Units)
Y
dimension
byte 2 (in
Units)
480–60000 (dec) 1890 (dec)
07 62 (hex)
Optional
Note: The range of values of the
Y dimension is between 2 to 5
times the values of the
X-dimension. Any value beyond
that range are clipped
appropriately and set to the
minimum and maximum values.
Sets the Y dimension of the
module (white or black
rectangle) in one-hundredths of
an inch.
The default width of this element
from the BCE is twice that of the
X dimension. To set the Y
dimension to default at 600 dpi
requires a value of 18.9, which
is specified as 1890 (dec) or 07
62 (hex).
The Units enumeration will be
set to 02 or 00 (hex), and these
two bytes will be 07 (hex) and
62 (hex). If not specified, then
the Y dimension will become
double that of the X dimension.
8–9 Rows Columns Rows: 4–44 (dec)
Columns: 1–4
(dec)
0 (dec)
00 (hex)
Optional
Manually set the number of
symbol rows. Automatic
operation specified by using 0.
See Section 9.5.3 Row and
Column Boundary Conditions.
Manually set the number of
symbol columns. Automatic
operation specified by using 0.
10–15 Reserved — — — —
Bytes MSB LSB Range
Default 
(if not
specified)
Definition

Lexmark MS812dn Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	4 s
Print margins (top, bottom, right, left)	4.2 mm
Print speed (black, normal quality, A4/US Letter)	66 ppm
Duplex print speed (black, normal quality, A4/US Letter)	40 ppm
Security algorithms	802.1x RADIUS, EAP-TLS, EAP-TTLS, LEAP, MD5, PEAP
Supported network protocols (IPv4)	TCP, UDP, AppleTalk, LPR/LPD, Direct IP, FTP, TFTP, ThinPrint, IPP
Printing colors	Black
Country of origin	China
Maximum duty cycle	300000 pages per month
Recommended duty cycle	5000 - 50000 pages per month
Number of print cartridges	1
Page description languages	Microsoft XPS, PCL 5e, PCL 6, PDF 1.7, PostScript 3, PPDS, XHTML
Maximum internal memory	2560 MB
Sound power level (standby)	32 dB
Sound pressure level (printing)	58 dB
Sound pressure level (quiet mode)	53 dB
Total input capacity	550 sheets
Maximum input capacity	4400 sheets
Total number of input trays	2
Maximum number of input trays	6
Multi-Purpose tray input capacity	100 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Maximum print size	216 x 356 mm
Paper tray media types	Card stock, Envelopes, Labels, Plain paper
Paper tray media weight	60 - 176 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Standard interfaces	USB 2.0
Optional connectivity	Parallel, Serial (RS-232), Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Other operating systems supported	Novell NetWare 5.x, Novell NetWare 6.x, Novell Open Enterprise Server
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Power consumption (off)	0.5 W
Power consumption (standby)	4.1 W
Power consumption (printing)	830 W
Package weight	27430 g
Networking features	Gigabit Ethernet
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Compatible operating systems	Windows XP (32/64bit)\\r Windows Vista (32/64bit)\\r Windows 7 (32/64bit)\\r Mac OS X 10.5, 10.6, 10.7, 10.8\\r SUSE Linux Enterprise Server 10, 11\\r SUSE Linux Enterprise Desktop 10, 11\\r Red Flag Linux Desktop 6.0\\r Linpus Linux Desktop 9.6\\r Debian GNU/Linux 5.0, 6.0\\r Red Hat Enterprise Linux WS 4.0, 5.0, 6.0\\r Ubuntu Linux 11.04, 11.10, 12.04\\r openSUSE Linux 11.3, 11.4, 12.1\\r PCLinuxOS 2011.9\\r Mint Linux 9, 10, 11, 12\\r Fedora Linux 14, 15\\r Unix Sun Solaris SPARC 9, 10\\r Unix HP-UX 11.11, 11.23, 11.31\\r Unix Sun Solaris x86 10, 11\\r Unix IBM AIX 5.3, 6.1, 7.1
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Sustainability certificates	ENERGY STAR
Display	LCD
Certification	RAL-UZ, CAN/CSA, ICES, BSMI, CNS, VCCI, FCC, UL, IEC, CE, CB, GS (TÜV), SEMKO, C-tick, CCC, CISPIR, EK, ECMA, TED
Product color	Grey, White
Operating altitude	0 - 2896 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	425 x 510 x 419 mm
