Lexmark MX310dn Manual

6 Follow the prompts and answer any questions that appear on the screen.
• To accept the defaults, press Enter.
• To answer yes/no questions, type y, n, or ?, and then press Enter.
• When a message appears telling you the installation was successful, type q to quit.
Note: Your specific printer driver may not be included in the standard package. Check your Software and
Documentation CD or the Lexmark Web site to determine if there are any software plugins available. For more
information, see “Plugin Manager utility (software updates)” on page 31.
Finding space to install the printer drivers package
Some operating systems require you to install printer drivers in a particular directory. If the file system containing
the directory is full, you can create a symbolic link that points to the real directory in another file system which has
more file space. The operating system treats the symbolic link as a real directory, but the files are actually installed
on another drive.
1 Create a directory where you want the packages to actually be installed.
For example, to install in the /disk2 file system, type:
# mkdir /disk2/lexmark
2 Create a symbolic link that points to the directory you just created from the directory where the operating system
requires the files.
For example, if the operating system requires the files to be in /opt/lexmark, type:
# ln -s /disk2/lexmark /opt/lexmark
3 Continue with the installation of printer drivers in the folder /disk2/lexmark.
Removing the printer drivers package
A system administrator can remove the printer drivers package using the utilities in the table below.
Depending on your operating system, mark the printer drivers package for removal after you start the program. You
can also type the names of the printer drivers package you want to remove from the command line. For more
information, see the documentation that came with your operating system.
Operating system Package removal tool
HP-UX
sam
IBM AIX
smit
RedHat Linux
SuSe Linux
rpm -e
Linspire Linux
Debian GNU/Linux
dpkg -r
Sun Solaris
pkgrm
13

Lexmark MX310dn Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	33 ppm
Duplex print speed (black, normal quality, A4/US Letter)	14 ppm
Finishing option	No
All-in-one functions	Copy, Fax, Print, Scan
Supported media weight(s)	60 - 90 g/m²
Color all-in-one functions	Scan
Package dimensions (W x D x H)	19.09 x 21.65 x 22.48 \
Supported media weight (imperial)	24 lbs
Country of origin	China
Maximum duty cycle	50000 pages per month
Recommended duty cycle	250 - 6000 pages per month
Page description languages	Microsoft XPS, PCL 5e, PCL 6, PDF 1.7, PostScript 3, PPDS
Copier resize	25 - 400 %
Copy speed (black, normal quality, A4)	33 cpm
Scanner type	Flatbed & ADF scanner
Maximum scan area	216 x 356 mm
Duplex scan speed (black)	43 ppm
Duplex scan speed (color)	20 ppm
Optical scanning resolution	600 x 1200 DPI
Faxing	Mono faxing
Modem speed	33.6 Kbit/s
Fax transmission speed	3 sec/page
Total input capacity	300 sheets
Total output capacity	150 sheets
Maximum input capacity	850 sheets
Total number of input trays	2
Maximum number of input trays	3
Auto document feeder (ADF) input capacity	50 sheets
Envelopes sizes	7 3/4, 9, 10, DL
Maximum print size	-
Paper tray media types	Card stock, Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Display	LCD
Display diagonal	2.4 \
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Supported network protocols (IPv4)	TCP/IP, AppleTalk, TCP, UDP
Supported network protocols (IPv6)	TCP/IP
Internal memory	256 MB
Processor frequency	800 MHz
Sound pressure level (copying)	54 dB
Sound pressure level (printing)	53 dB
Sound pressure level (scanning)	55 dB
Sound pressure level (duplex printing)	52 dB
Power consumption (average operating)	- W
Package depth	550 mm
Package width	485 mm
Package height	571 mm
Package weight	22500 g
Operating altitude	0 - 2896 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Other operating systems supported	Novell NetWare 5.x, Novell NetWare 6.x, Novell Open Enterprise Server
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Sustainability certificates	ENERGY STAR
Certification	Blue Angel (RAL-UZ-122), CAN/CSA-C22.2 60950-1, CSA E60825-1, ICES-003 B, BSMI B, CNS 13438, VCCI B, US FDA, FCC B, UL 60950-1, IEC 320-1, EN/IEC 60320-1, CE B, CB IEC 60950-1, EN 62311, EN 60950-1, EN/IEC 61000-3, EN 55022 B, EN 55024, EN/IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, SMA C-tick B, CCC B, CISPIR 22 B, EK Mark, N Mark, ECMA-370, TED

Weight and Dimensions

Depth	472 mm
Width	399 mm
Height	468 mm
Weight	20000 g
