3 Close the rear door.
4 Push the back of the standard tray.
5 Press down the rear duplex flap, then firmly grasp the jammed
paper, and then gently pull the paper out.
Note: Make sure all paper fragments are removed.
2
1
6 Insert the standard tray.
7 From the printer control panel, touch Done to clear the message
and continue printing.
[x]‑page jam, remove standard bin
jam. [203]
1 Firmly grasp the jammed paper on each side, and then gently pull
it out.
Note: Make sure all paper fragments are removed.
2 From the printer control panel, touch Done to clear the message
and continue printing.
[x]‑page jam, remove tray 1 to clear
duplex. [235–239]
1 Pull out the tray completely.
Note: Lift the tray slightly, and then pull it out.
1
3
2
24
