2 Flex the sheets back and forth to loosen them, and then fan them.
Do not fold or crease the paper. Straighten the edges on a level
surface.
3 Reload paper into the multipurpose feeder.
4 Slide the paper guide until it rests lightly against the edge of the
paper.
5 From the printer control panel, touch Done to clear the message
and continue printing.
[x]‑page jam, open automatic feeder top
cover. [28y.xx]
1 Remove all original documents from the ADF tray.
Note: The message is cleared when the pages are removed from
the ADF tray.
2 Open the ADF cover.
3 Firmly grasp the jammed paper on each side, and then gently pull
it out.
Note: Make sure all paper fragments are removed.
4 Close the ADF cover.
5 Open the scanner cover.
26
