2 From the printer control panel, touch Done to clear the message
and continue printing.
[x]‑page jam, remove tray 1 to clear
duplex. [235–239]
1 Pull out the tray completely.
Note: Lift the tray slightly, and then pull it out.
1
3
2
2 Push down the front duplex flap, then firmly grasp the jammed
paper, and then gently pull the paper to the right and out of the
printer.
Note: Make sure all paper fragments are removed.
1
2
3 Insert the tray.
4 From the printer control panel, touch Done to clear the message
and continue printing.
[x]‑page jam, open tray [x]. [24x]
1 Check which tray is indicated on the printer display, and then pull
the tray.
2 Firmly grasp the jammed paper on each side, and then gently pull
it out.
Note: Make sure all paper fragments are removed.
23
