Lexmark X422 Quick Reference Guide

Clearing jams
For more information on clearing jams, see the User’s Reference located on the
Publications CD.
Jams under the print cartridge or in the fuser
(200 or 201 Paper Jam, remove toner cartridge to
access)
1 Open the upper front door using the finger grips.
2 Remove the print cartridge.
CAUTION! The rear portion of the inside of the MFP may be hot.
Warning! Do not touch the photoconductor drum on the bottom of the
print cartridge.
3 Remove any jams. If paper is in fuser, pull carefully to avoid tearing..
4 Reinstall the print cartridge.
5 Close the upper front door.
6 Press ✓.
Jams behind the rear output bin door (202 Paper
Jam, open rear door to access)
1 Open the rear output bin door.
2 Remove any jams. You may have to remove the print cartridge to clear a jam
in this area. If paper is in fuser, pull carefully to avoid tearing.
3 Close the rear output bin door.
4 Press ✓.
Jams in a tray
1 Gently open the tray until you can see the jam.
2 Remove any jams.
If you see any print media above the metal stop, completely remove the tray.
Press down on the print media to lock the metal plate below it into place.
Reposition the print media under the metal stop.
3 Reinstall the tray.
4 Press ✓.
Jams under the MFP (230 Paper Jam, check duplex)
Print media can jam under the MFP and above tray 1 when the duplex function is in
use. To clear this type of jam:
Note: Jams under the MFP may not always be visible.
1 Completely remove tray 1.
2 Press down the green lever on the left under the MFP.
3 Remove any jams.
4 Grasp the tab on the rear door and pull the door open.
5 Press down the green lever on the right under the MFP.
6 Remove any jams.
7 Close the rear door, and then reinstall the tray.
8 Press ✓.
Jams in the scanner (290–293 Scanner jams)
To open the Automatic Document Feeder (ADF), push and hold the release button
on the left front side of the ADF and lift up. Remove jam.
Finger grips

Lexmark X422 Specifications

General

Print technology	Laser
Resolution color	300 x 300 DPI
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	21 ppm
I/O ports	Standard Ports: Ethernet 10/100BaseTX USB Compatible with USB 2.0 Specification Optional Network Ports: External 802.11b Wireless
Dimensions (WxDxH)	495 x 413 x 540 mm
Color all-in-one functions	Print
Print technology resolution	1200 DPI
Compatible operating systems	Apple Macintosh Operating Systems Supported: Apple Mac OS X Citrix MetaFrame: Citrix, MetaFrame and MetaFrame XP are registered trademarks or trademarks of Citrix Systems, Inc. in the U.S. and other countries. Microsoft Windows 2000 Server Terminal Services, with Citrix MetaFrame 1.8 or XP 1.0 Microsoft Windows NT 4.0 Terminal Server, with Citrix(R)MetaFrame(R) 1.8 or XP 1.0 Microsoft Windows 2003 Server Terminal Services, with Citrix MetaFrame XP 1.0 Linux Operating Systems Supported: Red Hat Linux 7.3, 8.0, 9.0 SuSE Linux 8.0, 8.1, 8.2 Microsoft Windows Operating Systems Supported: Microsoft Windows 2000 (Professional/Server/Advanced Server) Microsoft Windows NT (4.00/4.00 Server) Microsoft Windows Me Microsoft Windows XP Microsoft Windows Server 2003 (Standard, Enterprise) Microsoft Windows 98 2nd Edition Novell Operating Systems Supported: Novell Netware Enterprise Print Services (NEPS) with Lexmark NDPS IP Gateway Novell NetWare(R) 3.x, 4.x, 5.x, 6.x including full NDS and NDPS support Novell(R) Distributed Print ServicesTM (NDPS(TM)) 2.0 or later with Lexmark Printing Solution UNIX Operating Systems Supported: (SCO) UnixWare 7.0, 7.1, 7.1.1 Certified Solaris Ready by Sun Microsystems Compaq (Digital) UNIX 4.0D Compaq Tru64 UNIX 4.0F HP-UX 10.20, 11.00 IBM AIX 4.2.1, 4.3.3, 5.1 SCO OpenServer 5.0.4, 5.0.5, 5.0.6 SGI IRIX 6.5.x Sun Solaris 7, 8, 9 Sun Solaris x86 2.6, 7, 8 Other Operating Systems Supported: IBM iSeries or IBM AS/400 Systems with TCP/IP with OS/400 V3R1 or later using OS/400 Host Print Transform Virtually any platform supporting TCP/IP
Faxing	No
Modem speed	33.6 Kbit/s
Sound pressure level (printing)	52 dB
Total input capacity	350 sheets
Maximum input capacity	850 sheets
Maximum duty cycle	50000 pages per month
Network integrated ports	Ethernet 10/100BaseTX
Operating temperature (T-T)	16 - 32 °C
Market positioning	Business
