6-1. Specifications

6

Vehicle specifications

CT200h_OM_OM76066U_(U)

Tire section names

Bead

Sidewall

Shoulder

Tread

Belt

Inner liner

Reinforcing rubber

Carcass

Rim lines

Bead wires

Chafer
