8-1. Specifications
*1
: Minimum pedal clearance when depressed with a force of 300 N (30.6 kgf, 67.4 lbf)
while the engine is running.
When performing the brake pedal inspection, also be sure to check that the brake sys-
tem warning light is not illuminated when the engine is running. (If the brake system
warning light is illuminated, refer to P.432)
*2
: Make sure to confirm that the brake system warning light (yellow) does not illuminate. (If
the brake system warning light illuminates, refer to P.432)
17-inch tires
Brakes
Pedal clearance
*1
16 inch: 81 mm (3.2 in.) Min.
17 inch: 79 mm (3.1 in.) Min.
Pedal free play 1.0 - 6.0 mm (0.04 - 0.24 in.)
Brake pad wear limit 1.0 mm (0.04 in.)
Parking brake indicator
*2
When pushing the parking brake switch for 1 to 2 sec-
onds: comes on
When pulling the parking brake switch for 1 to 2 sec-
onds: turns off
Fluid type
SAE J1703 or FMVSS No. 116 DOT 3
SAE J1704 or FMVSS No. 116 DOT 4
Steering
Free play Less than 30 mm (1.2 in.)
Tires and wheels
Tire size 215/55R17 94V
Tire inflation pressure
(Recommended cold tire
inflation pressure)
Vehicle speed
Front tire and rear tire
kPa (kgf/cm
2
or bar, psi)
More than 160 km/h (100
mph)
320 (3.2, 46)
160 km/h (99 mph) or less 240 (2.4, 35)
