ELECTRICAL COMPONENTS
251
No.
FUSE
AMPERE
CIRCUIT
1
TURN 7.5 Turn signal lights
2
WIPER 20 Windshield wipers
3
HEATER 10
Air conditioning system,
Rear window defogger, Multiport
fuel injection system/sequential
multiport fuel injection system
4
FR FOG 15 Fog lights
5
ECU−IG 10
Power steering control system,
Charging system,
Vehicle skid control system
6
PWR−IG 15
Automatic headlight leveling
system, Moon roof,
Headlight cleaner,
Power seat switch,
Tilt and telescopic steering, Shift
lock system
7
GAUGE 10
Gauges and meters, service
reminder indicators and warning
buzzers,
Back−up lights,
Vehicle skid control system,
Multiport fuel injection
system/sequential multiport fuel
injection system, Automatic
transmission system
8
IGN 10
SRS, Multiport fuel injection
system/sequential multiport fuel
injection system
9
RR FOG 7.5 No circuit
10
FUEL OPN 10 Fuel opener system
No.
FUSE
AMPERE
CIRCUIT
11
RR CIG 15
Rear cigarette lighter,
Power outlet
12
FR CIG 15 Front cigarette lighter, SRS
13
A/C 7.5 Air conditioning system
14
P RR
DOOR
20
Rear door lock,
Rear power window
15
STOP LP 25
Stop lights,
High mounted stop light
16
RADIO
NO.2
15
Audio system,
Outside rear view mirror,
Shift lock system,
Air conditioning system
17
PANEL 7.5
Instrument panel lights,
Air conditioning system, Glovebox
light, Audio system
18
STARTER 7.5
Starting system,
Automatic transmission system,
Multiport fuel injection
system/sequential multiport fuel
injection system
19
TAIL 7.5
Tail lights, Side marker lights,
License plate lights
20
STOP−S 7.5
Shift lock system,
Height control system, Anti−lock
brake system,
Vehicle skid control system
21
RR S/HTR 15 No circuit
22
WASHER 20 Windshield washer
