2003 RX300 from Aug. 02’ Prod. (OM48442U)
– TRANSFER
Oil capacity
0.9 L (1.0 qt., 0.8 Imp. qt.)
Oil type Hypoid gear oil API GL–5
Recommended oil viscosity Above –18C (0F) SAE 90
Below –18C (0F) SAE 80W or 80W–90
– BRAKES
Pedal clearance
122 mm (5.0 in.) Min. *
1
Pedal free play 1 – 6 mm (0.04 – 0.24 in.)
Brake pad wear limit 1.0 mm (0.04 in.)
Parking brake lining wear limit 1.0 mm (0.04 in.)
Parking brake adjustment 5 – 7 clicks *
2
Fluid type SAE J1703 or FMVSS No. 116 DOT 3
*
1
: Minimum pedal clearance when depressed with the pressure of 490 N (50 kgf, 110 lbf) with the engine running
*
2
: Parking brake adjustment when depressed with the pressure of 294 N (30 kgf, 66 lbf)
– STEERING
Wheel free play
Less than 30 mm (1.2 in.)
Power steering fluid type Automatic transmission fluid DEXRON
II or III
