No. FUSE AMPERE CIRCUIT
18 ABS 3 7.5 Anti–lock brake system
19
H–LP R
UPR
15
Right–hand headlight
(high beam)
20
H–LP L
UPR
15
Left–hand headlight
(high beam)
21 A/F HTR 25 Air fuel ratio sensor
22 IGN 7.5
SRS system, Multiport fuel
injection/Sequential multiport fuel
injection system
23
RADIO
NO.2
7.5
Audio system, Multiplex
computer
24 CIG 15
Cigarette lighter, Outside rear
view mirrors, Power door lock
system
25
D RR
DOOR
20
Rear door lock, Rear power
window
26
PWR
OUTLET
15
Power outlets
27 FR FOG 15 Fog lights
28 SRS–IG 15 SRS system
29 ECU–IG 15
Telephone, Inside rear view
mirror, Anti–lock brake system,
Traction control system,
Multi–display
30 WIPER 25 Windshield wipers
31
P RR
DOOR
20
Rear door lock, Rear power
window
No. FUSE AMPERE CIRCUIT
32
P FR
DOOR
20
Front door lock, Front power
window
33 S/ROOF 20 Moon roof
34 HEATER 15 Air conditioning system
35 GAUGE 7.5
Multiplex computer, Service
reminder indicators
36 RR WIP 15 Rear window wiper
37 STOP 20
Stop lights, High mounted
stoplight, Anti–lock brake
system, Traction control system
38 OBD 7.5 On–board diagnosis system
39 SEAT HTR 15 Seat heater system
40 STARTER 7.5 Starting system
41 WASHER 20 Washer
42 RR FOG 7.5 No circuit
43 FR DEF 20
Rear window and outside rear
view mirror defogger
44 TAIL 10
Tail lights, Side marker lights,
License plate lights, Parking
lights
45 PANEL 7.5 Instrument panel lights
46 ABS 60 Anti–lock brake system
47 ALT 140 Charging system
48 RDI 40 Cooling fan system
