LEYBOLD DRYVAC DV 300 User Manual

Description
12 300750767_002_C3 - 12/2020 - © Leybold
1 Description
1.1 Design
The DRYVAC DV 200, DV 300, and DV 500 are single-stage dry compressing
screw vacuum pumps. They have optimized pumping speeds even at pres-
sures>100mbar.Thesemodelsareespeciallysuitedforshortcycleopera-
tion, e.g. load lock applications.
DRYVAC pumps are equipped as standard with all the typical features
required for applications in the process industry. For example, they have a
gas ballast device.
DRYVAC pumps are designed to provide reliability in harsh process duties.
They are optimized for handling typical gases from the production in the PV
and FPD industry. They excel through their robust design and meet industrial
safety requirements. They are equipped with a purge gas system that makes
possible rotor purge and shaft seal purge.
The DV 200 and DV 300 have the same motor. The required frequency con-
verter is installed at the pump.
All DRYVAC pumps have been prepared for direct fitting of a RUVAC roots
pump.
The pumps are water cooled. They are lubricated either with synthetic oil or
PFPE.
If synthetic oil and PFPE come into contact with each other they will emul-
sify. That’s why the pumps must only be run with the type of lubricant
specified for the pump. If you want to change the type of lubricant please
contact Leybold.
1.2 Supplied Equipment
■
Pump as described in Sections 1.1 and 1.4.1.
■
The pumps are filled with lubricant:
Synthetic oil LEYBONOL LVO 210 or PFPE LEYBONOL LVO 410
■
The pumps are purged with nitrogen for protection against corrosion. The
pump flanges have been blanked off with a sealing cap.
■
4x crane eyes M16
■
Plug for purge and gas ballast valve
■
Plug for purge gas pressure switch
NOTICE

LEYBOLD DRYVAC DV 300 Specifications

General

Category	Water Pump
Pumping Speed	300 m³/h
Frequency	50/60 Hz
Cooling	Air
Model	DRYVAC DV 300
