Description
6 300758785_002_C1 - 06/2019 - © Leybold
1 Description
The ECODRY plus is an eight-stage Roots pump. It is of the dry compressing
type and capable of evacuating chambers down to the medium vacuum
range.
The pump is connected to a single-phase supply using a mains power cable
and is powered via a built-in electronic drive unit. It is air-cooled. Bearings
and gears are lubricated using PFPE. The pump is therefore maintenance-
free from the customer’s perspective.
1.1 Supplied Equipment
The pump is delivered ready for use, except from a power cable. Inlet and
exhaust flanges are closed. The scope of delivery includes:
■
2 centering rings, 2 clamping rings, 2 blank flanges for the inlet and
exhaust flanges
■
D-sub 9-pin jumper for manual operation of the pump.
1.2 Technical Data
ECODRY plus 40 65 Tolerance
Maximum pumping speed without gas ballast 40 m³/h 55 m³/h ± 5 %
Ultimate partial pressure without gas ballast < 0.03 mbar
Ultimate partial pressure with gas ballast < 0.1 mbar
Maximum permissible inlet pressure 1050 mbar*
Max. perm. discharge pressure (relative to ambient) 200 mbar
Leak rate < 10
-5
mbar∙l/s
Water vapour tolerance with gas ballast 20 mbar 20 mbar
Water vapour capacity with gas ballast 300 g/h 500 g/h
Permissible ambient temperature +5 to +40 °C
Storage temperature -20 to +60 °C
Typical noise level without silencer, at ultimate pressure
(acc. to DIN EN ISO 2151)
< 52 dB(A)
Relative ambient atmospheric humidity 95%, non-condensing
Max. installation height up to 3000 m (NHN)*
Cooling Air
Leakage current in accordance with IEC 61010-1 < 3.5 mA
Max. contamination grade acc. to IEC 61010-1 2
Speed 12 600 RPM
Protection class IP 42
Intake flange DN 25 ISO-KF DN 40 ISO-KF
Discharge flange DN 16 ISO-KF
Weight, approx. 43 kg ± 1 kg
* For installation heights above 2000 m, an inlet pressure of 50 mbar should not be permanently exceeded.
