5
Please read and understand this entire manual before attempting to assemble, operate or install the
SAFETY INFORMATION
KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
Tools Required for Assembly (not included): Drill with 7/32 in. and 15/32 in. drill bits, stud finder, socket
PREPARATION
Estimated Assembly Time: 25 minutes
wrench 1/2, pencil, Phillips screwdriver, hammer, hex wrench, level.
WARNING
CAUTION
• Max screen size: 90 in.
product.
FAILURE TO READ, THOROUGHLY UNDERSTAND, AND FOLLOW ALL INSTRUCTIONS CAN •
RESULT IN SERIOUS PERSONAL INJURY, DAMAGE TO PERSONAL PROPERTY, OR VOIDING
OF FACTORY WARRANTY.
Do not attempt to install or assemble this product if the product or hardware is damaged or missing. •
The included hardware is designed for use on vertical walls constructed of wood studs or solid
concrete. A wood stud wall is defined as consisting of a minimum of 2x4 wooden studs
(2 in. wide by 4 in. deep) with a maximum of 5/8 in. drywall. The included hardware is not designed
for use with metal studs or cinder block walls. If you are uncertain about the construction of your wall,
please consult a qualified contractor or installer for assistance. For safe installation, the wall selected
for mounting must support 4 times the weight of the total load. If not, the surface must be reinforced
to meet this standard. The installer is responsible for verifying that the wall structure and hardware
used in any installation method will safely support the total load.
The maximum loading weight is 130 lbs. Use with products heavier than the maximum weight •
indicated may result in instability and possible personal injury.
Before beginning assembly of product, make sure all parts are present. Compare parts with package
contents list and hardware contents list. If any part is missing or damaged, do not attempt to assemble
the product.
Use this mounting system only for its intended use as described in these instructions. Do not use
attachments not recommended by the manufacturer.
•
Do not use outdoors.
•
WARNING: For STUD MOUNTING INSTALLATION, USE WALL SCREWS WITHOUT THE
PLASTIC ANCHORS. FOR CONCRETE STONE OR MASONRY INSTALLATIONS, USE ANCHORS.
DO NOT INSTALL INTO DRYWALL ALONE.
