LF UTILITECH RAD 42-90IN - Specifications

Dimensions and Mounting Configurations
SPECIFICATIONS
6
WALL PLATE
VESA INTERFACE
FULLY ASSEMBLED MOUNT
SIDE VIEW - EXTENDED & TILT
PRODUCT OVERVIEW
24 in. (609.6mm)
18 in. (457.2mm)
Max5.35 in.
(135.8mm)
5.90 in.
(150mm)
25.98 in. (660mm)
16 in. (406.4mm)
MAX: 600mm (23.62 in)
MAX: 400mm
(15.75 in.)
MIN: 200mm
(7.87 in.)
MAX: 430mm
(16.929 in.)
MAX: 650mm (25.590 in.)
36mm (1.42 in.)
MIN: 200mm (7.87 in.)
Min3.0 in.
(76mm)
-10
Tilt
+8
Tilt
0
0
