Hardware Used
II
x1
9. Insert anchors (II) into the wall and use a hammer
to lightly tap them into wall.
D
Mounting Template
Concrete installation
x4
12x60 mm Anchors
8. Pre-drill marked 4 holes with a 15/32 in. size
Masonry Drill Bit to a depth of 2.36 in.
Masonry Drill Bit
15/32 in. (12mm)
II
8
9
2.36 in. (60 mm)
Masonry Drill Bit
15/32 in. (12 mm)
7
D
Note: Use a bubble level to level the mounting
template (D).
7. Hold the mounting template (D) in the desired
position and use a pencil to mark 4 holes locations.
11
ASSEMBLY INSTRUCTIONS
