LG 22MA33A - Composite connection

18
ENGLISH
MAKING CONNECTIONS
Transmits the analogue video and audio signals from an external device to the TV. Connect the external device and the
TV with the composite cable as shown on the following illustration.
Check to ensure the cables are matched with the corresponding colour connection.
NOTE
Composite connection
DC
-IN
H
D
MI
IN
RGB IN
(
PC
)
US
B IN
5 V 0.5 A
(19 V )
VIDEO
AUDIO
L/MONO
AV IN
AUDIO OUT
R
R
L
AUDIO OUT
R
L
DVD / Blu-Ray / HD Cable Box /
HD STB / Gaming device
(Not Provided)
