ENGLISH
SPECIFICATIONS
SPECIFICATIONS
Panel Screen Type 550 mm Wide (22 inch)
Visible diagonal size : 550 mm
Pixel Pitch 349.5 um (H) x 349.5 um (V)
Video Signal Max. Resolution 1366 × 768 @ 60 Hz
Recommended Resolution 1366 × 768 @ 60 Hz
Horizontal Frequency 30 kHz to 69 kHz
Vertical Frequency 56 Hz to 61 Hz
Synchronization Type Separate Sync, Digital
Input Connector TV, D-Sub Analogue, CVBS, HDMI, USB
Speaker Out 5 W x 2
Power Rated Voltage 19 V 1.6 A
Power Consumption On Mode : 27 W (typ.)
Off Mode : 0.5 W
Dimensions (Width x Depth x Height)
Weight
With Stand
512.6 mm x 140.1 mm x 363.4 mm
3.2 kg
Without Stand
512.6 mm x 63.1 mm x 315.6 mm
3.0 kg
Environmental
conditions
Operating Temperature
Operating Humidity
10 °C to 35 °C
20 % to 80 %
Storage Temperature
Storage Humidity
-10 °C to 60 °C
5 % to 90 %
Product specifications shown above may be changed without prior notice due to upgrade of product functions.
22MA33A 22MA33B
