6
ENG
ENGLISH
ASSEMBLING AND PREPARING
Mounting on a table
1
Lift the monitor and place it on the table in an
upright position.
Install at least
100 mm
away from the wall to
ensure sufficient ventilation.
2
3
Press the (Power) button on the front of the
monitor to turn on the monitor.
100 mm
100 mm
100 mm
100 mm
y
Unplug the power cord prior to moving or
installing the monitor. There is risk of electric
shock.
CAUTION
Connect the Power cord to the monitor, then
plug the power cord into the wall outlet.
When you adjust the angle, do not hold the
bottom of the Monitor set frame as shown on
the following illustration, as may injure your
fingers.
Do not touch or press the screen when
adjusting the angle of the monitor.
Do not hold this set like below picture.Monitor
screen can detach from stand base and injure
your body.
WARNING
Tilt from +20 to -5 degrees up or down to adjust
the angle of the Monitor set to suit your view.
NOTE
Front Rear
To Next Page
