LG 26LX2R User Manual

19
Installation
When connecting with a component cable
S-VIDEO
PR
PB
Y
R
L
VIDEO
COMPONENT 1
AUDIO
VIDEO
AUDIO
R
L
VIDEO
AUDIO
R
L
MONITOR
OUT
B
R
(R) AUDIO (L)
VIDEO
DVD
TV Back panel (32inch)
R
L
COMPONENT2
AUDIO
VIDEO
B
R
(R) AUDIO (L)
DVD
1
1
1
2
2
2
S-VIDEO
AUDIO
VIDEO
R
L
R
PR PB Y
L
VIDEO
COMPONENT 1
AUDIO
VIDEO
AUDIO
R
L
MONITOR
OUT
B
R
(L)AUDIO(R)
VIDEO
DVD
TV Back panel (26inch)
1
2
3
4
5
Connect the video outputs (Y, PB, PR) of the DVD
to the COMPONENT1 VIDEO (Y, PB, PR) jacks on
the set.
Connect the audio outputs of the DVD to the COM-
PONENT1 AUDIO jacks on the set.
Turn on the DVD player, insert a DVD.
Select Component 1 input source with using the
INPUT button on the remote control.
- If connected to COMPONENT2, select Component2
input source.
Refer to the DVD player's manual for operating
instructions.
• Component Input ports
To get better picture quality, connect a DVD player
to the component input ports as shown below.
Y PB
PR
Component ports on the TV
Y
Y
Y
Y
Pb
B-Y
Cb
P
B
Pr
R-Y
Cr
PR
Video output ports
on DVD player
TV side panel (32, 26inch)
