53
Reference
Set ID
Set ID
- Use this function to specify a TV ID number.
- Refer to ‘Real Data Mapping’. See page 54.
• Baud rate : 9600 bps (UART)
• Data length : 8 bits
• Parity : None
• Stop bit : 1 bit
• Communication code : ASCII code
* Use a crossed (reverse) cable.
Communication Parameters
Communication Parameters
1. Press the MENU button and then use
DD
/
EE
button to select the
SPECIAL menu.
2. Press the
GG
button and then use
DD
/
EE
button to select Set ID.
3. Press the
GG
button and then use
DD
/
EE
button to adjust Set ID to
choose the desired TV ID number. The adjustment range of
Set ID
is 1 ~ 99.
4. Press EXIT button to return to normal TV viewing.
T
ransmission
* [Command 1]: First command. (k, x or m)
* [Command 2]: Second command.
* [Set ID]: You can adjust the set ID to choose desired moni-
tor ID number in Special menu. Adjustment range
is 1 ~ 99. When selecting Set ID ‘0’, every con-
nected TV set is controlled. Set ID is indicated as
decimal (1~99) on menu and as Hexa decimal
(0x0~0x63) on transmission/receiving protocol.
* [DATA]: To transmit command data.
Transmit ‘FF’ data to read status of command.
* [Cr]: Carriage Return
ASCII code ‘0x0D’
* [ ]: ASCII code ‘space (0x20)’
[Command1][Command2][ ][Set ID][ ][Data][Cr]
T
T
ransmission / Receiving Protocol
ransmission / Receiving Protocol
OK Acknowledgement
* The Monitor transmits ACK (acknowledgement) based on
this format when receiving normal data. At this time, if the
data is data read mode, it indicates present status data. If
the data is data write mode, it returns the data of the PC
computer.
[Command2][ ][Set ID][ ][OK][Data][x]
Error Acknowledgement
* The Monitor transmits ACK (acknowledgement) based on
this format when receiving abnormal data from non-viable
functions or communication errors.
*
: Refer to ‘02~03 Input select’. See page 54.
[Command2][ ][Set ID][ ][NG][Data][x]
01. Power k a 0 ~ 1
02. Input Select (Main Picture) x b
*
03. Input Select (Sub Picture) x y
*
04. Aspect Ratio k c 0 ~ 3
05. Screen Mute k d 0 ~ 1
06. Volume Mute k e 0 ~ 1
07. Volume Control k f 0 ~ 64
08. Contrast k g 0 ~ 64
09. Brightness k h 0 ~ 64
10. Color k i 0 ~ 64
11. Tint k j 0 ~ 64
12. Sharpness k k 0 ~ 64
13. OSD Select k l 0 ~ 1
14. Key Lock k m 0 ~ 1
15. Balance k t 0 ~ 64
16. Key m c Key Code
COMMAND 1 COMMAND 2 DATA
(Hexadecimal)
Command Reference List
Command Reference List
Prev.
Menu
Language
Key lock
Set ID
G
Caption/Text
Demo
Front light
SPECIAL
1
Data 1: Illegal Code
2: Not supported function
**Error messages
1. Illegal ID : If Wrong or no ID in the command is written.
2. B_TokenLength !=2 : If the first argument of the command
does not equals to 2.
3. Error ==TOKEN_ERROR : If some Special character or
Numeric are written to the first argument of the command
or wrong Space position is written to the first argument of
the command.
4. Illegal Opcodes : If the Wrong Alphabet is written to the
first argument of the command.
5. Illegal Params : If the Wrong parameter is supplied to the
end of the command line (means that value of the parame-
ter that is not supported).
To Next Page
