ENGLISH
28
MAKING CONNECTIONS
Headphone connection
Transmits the headphone signal from the TV to an external device. Connect the TV with the headphone as
shown on the following illustration.
Headphone
(Not Provided)
AUDIO menu items are disabled when connecting a headphone.
When changing AV MODE with a headphone connected, the change is applied to video but not to
audio.
Headphone impedance: 16
Max audio output of headphone: 9 mW to 15 mW
Headphone jack size: 0.35 cm
NOTE
